7.5.2 Oiling
Lubricate the points shown in the figures.
Oil to use : page 30
1. Fulcrum of auxiliary transmission shift lever
2. Rotary clutch lever fulcrum
3. Fulcrums on cutting height adjust linkage
4. Brake arm fulcrum
5. Drive lever fulcrum
6. Brake pedal fulcrum
7. Fulcrums on cutting blade shield (also on the other side.)
7
– 36 –
Maintenance
6.
7.
2.
7.
3.
5.
3.
4.
1.
7.
