4
4. Controls and Components
Name of Components
Controls and Components
– 10 –
Differential Lock Lever
Drive Lever
Throttle Lever
Cutting Height Adjust Lever
Rotary Clutch Lever
Parking Brake Lock Lever
Brake Pedal
Aux. Transmission Shift Lever
Cutting Blade Shield
Forward
Backward
Grass Outlet
Head Lamp Switch
Main Switch
Choke Knob
