SETUP AND CALIBRATION, CONT.
Unit1= (Weighing Unit 1)
Press the TARE/ENTER key to show the current value. If the setting displayed is acceptable,
press the TARE/ENTER` key again to save it. Otherwise, use the ASTERISK/UP ARROW key to
toggle to a new setting and then press the TARE/ENTER key to save it. Allowable values are:
0 = none
4 = oz (ounces)
1= tn (tons)
5 = kg (kilograms)
2= g (grams)
6 = tonnes (metric tons)
3 = lb (pounds)
7 = lb/oz (pounds/ounces)
int= (Interval Setting)
Press the TARE/ENTER key to show the current value.
If LFt = 1 (Legal For Trade = YES), use the ASTERISK/UP ARROW key to toggle to a
new setting and then press the TARE/ENTER key to save it. Allowable values are: 1, 2, 5,
10, 20 or 50.
If LFt=0 (Legal For Trade = NO), use the ASTERISK/UP ARROW key to toggle to a new
setting and then press the TARE/ENTER key to save it. Allowable values are: 1 through 99.
In either case, if the setting displayed is acceptable, press the TARE/ENTER key again it.
dPP= (Decimal Point Setting)
Press the TARE/ENTER key to show the current value. If the setting displayed is acceptable,
press the TARE/ENTER` key again to save it. Otherwise, use the ASTERISK/UP ARROW key to
toggle to a new setting and then press the TARE/ENTER key to save it. Allowable values are:
0, 1, 2 or 3.
0 = XXXXXX
2 = XXXX.XX
1= XXXXX.X
3 = XXX.XXX
CAP= (Capacity)
Press the TARE/ENTER key to show the current value. If the setting displayed is acceptable,
press the TARE/ENTER` key again to save it. Otherwise, use the ASTERISK/UP ARROW key to
toggle to a new setting and then press the TARE/ENTER key to save it. Allowable values are: 1
through 999,999. NOTE: Capacity cannot exceed 999,999.
Unit2= (Weighing Unit 2)
Press the TARE/ENTER key to show the current value. If the setting displayed is acceptable,
press the TARE/ENTER` key again to save it. Otherwise, use the ASTERISK/UP ARROW key to
toggle to a new setting and then press the TARE/ENTER key to save it. Allowable values are:
0 = none
4 = oz (ounces)
1= tn (tons)
5 = kg (kilograms)
2= g (grams)
6 = tonnes (metric tons)
3 = lb (pounds)
7 = lb/oz (pounds/ounces)
NOTE: The selection for Unit2 cannot be the same as Unit1. In addition, dependent upon
the selection for Unit1 and the interval and decimal point settings, not all unit combinations
are available.
