kVent – rel 3.1 – 22/06/2018
15
3.2 Unit schema
1 Ga01 Supply temperature 1 Gb01 Fire alarm 1 Gc01 Cool/Heat 1 Gd01 Supply fan 1 Exhaust fan
2 Ga06 Return temperature 2 Gb03 Fan overload 2 Gc03 Cooling 1 2 Gd02 Exhaust fan 2 Supply fan
3 Ga11 External temperature 3 Gb05 Humidifier alarm 3 Gc05 Cooling 2 3 Gd03 Heating 4 th-Tune
4 Ga16 Exhaust temperature 4 Gb07 Remote On 4 Gc07 Heating 1 4 Gd04 Reverse
6 Ga26 Back water temperature 5 Gb09 Summer/Winter 5 Gc09 Reverse 1 5 Gd05 Cooling
9 Ga41 Discharge temperature 6 Gb11 Cooling alarm 6 Gc11 Heating 2 6 Gd06 Heat recovery
10 Ga 46 Preheater back water temp. 8 Gb15 Freeze alarm 7 Gc13 Reverse 2 7 Gd07 Preheater
11 Ga51 After preheater temp. 9 Gb17 Heating alarm 8 Gc15 Reheat 8 Gd08 Mix
12 Ga56 CO2 sensor 10 Gb19 Eco 9 Gc17 Exhaust air damper 9 Gd09 Humidifier
13 Ga61 Supply air pressure 11 Gb21 Precomfort 10 Gc19 Recovery 10 Gd10 Reheater
14 Ga66 Exhaust air pressure 12 Gb23 Comfort 11 Gc21 Preheater 11 Gd11 IEC
15 Ga 71 Supply humidity 13 Gb25 Supply filter alarm 12 Gc23 Humidifier 12 Gd12 Cool/Heat signal
24 GaB6 VOC sensor 14 Gb27 Supply filter alarm 2 13 Gc25 Alarm 13 Gd13 Fresh Damper
25 GaC1 Fresh air humidity 15 Gb29 Return filter alarm 14 Gc27 Supply fan 15 Gd15 Main cool req. Optional
26 GaC6 Hepa filter 1 21 Gb41 Supply air flow switch 15 Gc29 Exhaust fan 17 Gd17 Main Heat req. Optional
27 GaD1 Hepa filter 2 22 Gb43 Return air flow switch 17-18 Gc33-35 Heat Op/Cl 19 Gd19 ReHeat req. Optional
23 Gb45 Recovery clogged 19-20 Gc37-39 Cool Op/Cl 20 Gd20 PreHeat req. Optional
24 Gb47 Door Switch 21-22 Gc41-43 Cool/Heat Op/Cl
26 Gb51 External generic alarm 23-24 Gc45-47 Heat rec Op/Cl
25-26 Gc49-51 Mix Op/Cl
27-28 Gc53-55 Preheat Op/Cl
29-30 Gc57-59 Reheat Op/Cl
35 Gc69 IEC humidifer
36 Gc71 Recovery step 1
37 Gc73 Recovery step 2
FRESH
XHAUST
AI3
DI1
DI2
DI3
DI4
DI5
DI6
DI10
DI11
DI13
DI14
AI26
MB4
DO14
AO1
DO15
AO2
MB1
DO1
DO5
DO2
DO4
DO8
AO10
DO9
A013
DO1
0
DO11
DO12
DO35
DO13
AO8
