7.2 Table of alarms
Code
Description
on display
Reset
Action
Variable name
BMS
BacNet
A000 Supply temperature probe not working Auto reset Stop unit Al_SupplyTempPrb DI1000 BV1000
A001 Cooling device alarm User reset Stop cooling Al_Cool DI1001 BV1001
A002 Antifreeze alarm by DIN
Auto reset until counter (3
in 3600s)
Stop unit, force heating
at 100%
Al_AFreezeDIN DI1002 BV1002
A003 Prototype software Auto reset Stop unit Al_SwPrototype DI1003 BV1003
A004 High number of retain memory writings User reset None Al_retain DI1004 BV1004
A005 Error in retain memory writings User reset None Al_Err_retain_write DI1005 BV1005
A006 Return temperature probe broken not working Auto reset
Switch to supply
regulation
Al_RetTempPrb DI1006 BV1006
A007 External temperature probe broken not working Auto reset
Disable external
compensation
Al_ExtTempPrb DI1007 BV1007
A008 CO2 air quality probe not working Auto reset Disable CO2 regulation Al_RetAir_CO2_Lev_Prb DI1008 BV1008
A009 Exhaust temperature probe not working Auto reset Stop unit Al_ExhTempPrb DI1009 BV1009
A010 th-Tune offline Auto reset
Disable room
compensation
Al_Offline_THTN_1 DI1010 BV1010
A011 Supply temperature out of range Auto reset None Al_LowSupplyTemp DI1011 BV1011
A012 Supply air flow alarm User reset Stop unit Al_SupplyAirFlwSwWarn DI1012 BV1012
A013 Return air flow alarm User reset Stop unit Al_RetAirFlwSwWarn DI1013 BV1013
A014 Humidifier alarm Auto reset Stop humidifier Al_Hum DI1014 BV1014
A015 Humidifier maintenance required Auto reset None Al_HumWorkHrsWarn DI1015 BV1015
A016 Return fan maintenance required Auto reset None Al_RetFanWorkHrsWarn DI1016 BV1016
A017 Supply fan maintenance required Auto reset None Al_SupplyFanWorkHrsWarn DI1017 BV1017
A018 Reheating coil maintenance required Auto reset None Al_ReheatCoilWorkHrsWarn DI1018 BV1018
A019 Heat recovery maintenance required Auto reset None Al_HeatExchgWorkHrsWarn DI1019 BV1019
A020 Supply filters alarm Auto reset None Al_Filters DI1020 BV1020
A021 th-Tune clock not working Auto reset None Al_ThTune_ClkBrd DI1021 BV1021
A022 th-Tune temperature probe not working Auto reset
Disable room
temperature regulation
Al_ThTune_TempPrb DI1022 BV1022
A023 th-Tune humidity probe not working Auto reset
Disable room humidity
regulation
Al_ThTune_HumPrb DI1023 BV1023
A024 BMS offline Auto reset None Al_BMS_Offline DI1024 BV1024
A025 Supply differential pressure probe not working Auto reset None Al_SupplyAirP_Prb DI1025 BV1025
A026 Return differential pressure probe not working Auto reset None Al_RetAirP_Prb DI1026 BV1026
A027 Fire alarm by digital input User reset
Stop unit, force fan at fire
speed
Al_Fire DI1027 BV1027
A028 Heating coil water temp.probe not working Auto reset
Stop unit, force valve at
100%
Al_HeatCoilTempPrb DI1028 BV1028
A029 Preheating coil water temp.probe not working Auto reset
Stop unit, force valve at
100%
Al_PreHeatCoilTempPrb DI1029 BV1029
A030 After preheating coil temp.probe not working Auto reset Disable preheater Al_AfterPreHeatCoilTempPrb DI1030 BV1030
A031 Heating device alarm
Auto reset until counter (3
in 3600s)
Stop heating Al_Heat DI1031 BV1031
A032 Fire alarm by temperature User reset
Stop unit, force fan at fire
speed
Al_FireExh DI1032 BV1032
A033 Antifreeze alarm by heat back water temp.
Auto reset until counter (3
in 3600s)
Stop unit, force valve at
100%
Al_AFreezePRB DI1033 BV1033
A034 Antifreeze alarm by preheat back water temp.
Auto reset until counter (3
in 3600s)
Stop unit, force valve at
100%
Al_AFreezePreHeatPRB DI1034 BV1034
A035 Fans overload alarm Auto reset Stop unit Al_FansOvld DI1035 BV1035
A036 Supply humidity probe not working Auto reset Stop humidifier Al_SupplyAirHum_Prb DI1036 BV1036
A037 Unit configuration not allowed Auto reset Stop unit Al_UnitCfgError DI1037 BV1037
A038 Supply fan - Offline Auto reset Stop unit Al_Offline_ZA_1 DI1038 BV1038
A039 Supply fan - Line Fault Auto reset Stop unit Al_LineFault_ZA_1 DI1039 BV1039
A040 Supply fan - Motor blocked Auto reset Stop unit Al_MotorBlock_ZA_1 DI1040 BV1040
A041 Supply fan - Fire alarm Auto reset Stop unit Al_FireAlrm_ZA_1 DI1041 BV1041
A042 Supply fan - Uin Low (FW 10) Auto reset Stop unit Al_UIN_LO_ZA_1 DI1042 BV1042
A043 Supply fan - Uin High (FW 10) Auto reset Stop unit Al_UIN_HI_ZA_1 DI1043 BV1043
A044 Supply fan - UZK low Auto reset Stop unit Al_UZK_Low_ZA_1 DI1044 BV1044
A045 Supply fan - UZK high Auto reset Stop unit Al_UZK_High_ZA_1 DI1045 BV1045
A046 Supply fan - IGBT fault Auto reset Stop unit Al_IGBTfault_ZA_1 DI1046 BV1046
A047 Supply fan - Earth-GND fault Auto reset Stop unit Al_EarthGNDfault_ZA_1 DI1047 BV1047
A048 Supply fan - Peak current error Auto reset Stop unit Al_PeakCurrent_ZA_1 DI1048 BV1048
A049 Supply fan - Hall sensor error Auto reset Stop unit Al_HallSensor_ZA_1 DI1049 BV1049
A050 Supply fan - Offline Auto reset Stop unit Al_Offline_EBM_1 DI1050 BV1050
A051 Supply fan - Phase Failure User reset Stop unit Al_PhaseFault_EBM_1 DI1051 BV1051
A052 Supply fan - Motor blocked User reset Stop unit Al_MotBlocked_EBM_1 DI1052 BV1052
A053 Supply fan - Mains undervolt. User reset Stop unit Al_MainsUnderV_EBM_1 DI1053 BV1053
A054 Supply fan - Mains overvoltage User reset Stop unit Al_MainsOverV_EBM_1 DI1054 BV1054
A055 Supply fan - DC-link overvoltage User reset Stop unit Al_DClinkOverV_EBM_1 DI1055 BV1055
A056 Supply fan - DC-link undervoltage User reset Stop unit Al_DClinkUnderV_EBM_1 DI1056 BV1056
A057 Supply fan - Motor overheat User reset Stop unit Al_MotSuperHeating_EBM_1 DI1057 BV1057
A058 Supply fan - Intern.circ.overheat User reset Stop unit Al_IntCircSuperHeat_EBM_1 DI1058 BV1058
A059 Supply fan - Out stage overheat. User reset Stop unit Al_OutStageSuperHeat_EBM_1 DI1059 BV1059
A060 Supply fan - Hall sensor error User reset Stop unit Al_HallSenErr_EBM_1 DI1060 BV1060
A061 Supply fan - Communic. Error User reset Stop unit Al_CommunicationErr_EBM_1 DI1061 BV1061
A062 Supply fan - Generic error User reset Stop unit Al_GenericErr_EBM_1 DI1062 BV1062
A063 Supply fan - Out stage high temp. Auto reset Stop unit Al_OutStageHighTemp_EBM_1 DI1063 BV1063
A064 Supply fan - Int.circ.high temp. Auto reset Stop unit Al_InternCircHighTemp_EBM_1 DI1064 BV1064
A065 Supply fan - Motor high temp. Auto reset Stop unit Al_MotHighTemp_EBM_1 DI1065 BV1065
A066 Supply fan - DC-link volt.low Auto reset Stop unit Al_DClinkV_Low_EBM_1 DI1066 BV1066
A067 Supply fan - Lim.mains power Auto reset Stop unit Al_LimMainsPwr_EBM_1 DI1067 BV1067
A068 Supply fan - Lim.mains current Auto reset Stop unit Al_LimMainsA_EBM_1 DI1068 BV1068
A069 Supply fan - Brake mode Auto reset Stop unit Al_BrakeMode_EBM_1 DI1069 BV1069
A070 Supply fan - Cable break Auto reset Stop unit Al_CableBreak_EBM_1 DI1070 BV1070
A071 Supply fan - Ice protection Auto reset Stop unit Al_IceProtection_EBM_1 DI1071 BV1071
A072 Supply fan - Heating: motor stop Auto reset Stop unit Al_HeatMotStopped_EBM_1 DI1072 BV1072
A073 Supply fan - Speed under limit Auto reset Stop unit Al_SpeedUnderLim_EBM_1 DI1073 BV1073
A074 Supply fan - DC-voltage high Auto reset Stop unit Al_DC_VoltageHigh_EBM_1 DI1074 BV1074
A075 Supply fan - Supply volt.high Auto reset Stop unit Al_SupplyVoltageHigh_EBM_1 DI1075 BV1075
A076 Supply fan - Line imp. High Auto reset Stop unit Al_LineImpHigh_EBM_1 DI1076 BV1076
A077 Return fan - Offline Auto reset Stop unit Al_Offline_ZA_2 DI1077 BV1077
A078 Return fan - Line Fault Auto reset Stop unit Al_LineFault_ZA_2 DI1078 BV1078
A079 Return fan - Motor blocked Auto reset Stop unit Al_MotorBlock_ZA_2 DI1079 BV1079
A080 Return fan - Fire alarm Auto reset Stop unit Al_FireAlrm_ZA_2 DI1080 BV1080
