Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
29
Mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
Y0ax Application version UDInt R GeneralMng.OsVersion[2] IR184 PIV184
Y0ax Application version UDInt R GeneralMng.OsVersion[3] IR186 PIV186
Y0ay
Type of board (12 = c.pCO, 13 = uPC, 14 = c.pCO
mini) and size (10 = Large, 11 = Medium, 12 =
Small, 13 = XL, 20 = Basic, 21 = Enhanced, 22 =
High End)
UDInt R BoardTyp[1] IR188 PIV188
Y0ay
Type of board (12 = c.pCO, 13 = uPC, 14 = c.pCO
mini) and size (10 = Large, 11 = Medium, 12 =
Small, 13 = XL, 20 = Basic, 21 = Enhanced, 22 =
High End)
UDInt R BoardTyp[2] IR190 PIV190
Y0ay Automatically generated UDInt R MemWritingsNo IR192 PIV192
Y0ay Program speed in ms UInt ms R PrgCycleMs IR194 PIV194
Y0ay Program speed in CyclePerSecond Real R CyclesPerSecond IR195 AV195
Y0ay PollingTime UDInt s R PollingTime IR196 PIV196
6.2 SET menu in main mask
Mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
Z00a Temperature setpoint Real °C R TempRegSetP IR1 AV1
Z00a Temperature regulation probe type USInt 1 R AppTempReg IR2 PIV2
Z00a Actual room temperature setpoint Real °C R CurrRoomTempSetP_Val IR3 AV3
Z00a Actual humidity setpoint Real R CurrHumSetP_Val IR4 AV4
Z00a Current air quality setpoint Real R CurrAirQualitySetP_Val IR5 AV5
Z00a Current air quality setpoint Real R VOC_QualitySetP_Val IR6 AV6
Z00b Air flow current setpoint Real m3h R CurrAirFlwSetP_Val IR7 AV7
Z00b Current air flow setpoint Real m3h R CurrRetAirFlwSetP_Val IR8 AV8
Z00b VAV supply setpoint Real Pa R VAV_SupplySet IR9 AV9
Z00b CAV supply setpoint Real m3h R CAV_SupplySet IR10 AV10
Z00b Unit of measure for user interface DInt 6 R Uom_Msk
Z00b VAV return setpoint Real Pa R VAV_RetSet IR11 AV11
Z00b CAV return setpoint Real m3h R CAV_RetSet IR12 AV12
Z00b Unit of measure for user interface DInt 6 R Uom_Msk
Z001 Supply temperature setpoint - Economy Real 22.0 °C
SupplyMinSet...SupplyMaxSe
t
R/W
UnitSetP.SupplyTempSetP.Eco
nomy
HR1 AV1
Z002 Supply temperature setpoint - PreComfort Real 22.0 °C
SupplyMinSet...SupplyMaxSe
t
R/W
UnitSetP.SupplyTempSetP.Pre
Comfort
HR2 AV2
Z003 Supply temperature setpoint - Comfort Real 22.0 °C
SupplyMinSet...SupplyMaxSe
t
R/W
UnitSetP.SupplyTempSetP.Com
fort
HR3 AV3
Z004 Room temperature setpoint - Economy Real 22.0 °C SetMinLimit...SetMaxLimit R/W
UnitSetP.RoomTempSetP.Econ
omy
HR4 AV4
Z005 Room temperature setpoint - PreComfort Real 22.0 °C SetMinLimit...SetMaxLimit R/W
UnitSetP.RoomTempSetP.PreC
omfort
HR5 AV5
Z006 Room temperature setpoint - Comfort Real 22.0 °C SetMinLimit...SetMaxLimit R/W
UnitSetP.RoomTempSetP.Comf
ort
HR6 AV6
Z007 Humidity setpoint - Economy Real 50.0 %rh 0.0...100.0 R/W UnitSetP.HumSetP.Economy HR7 AV7
Z008 Humidity setpoint - PreComfort Real 50.0 %rh 0.0...100.0 R/W UnitSetP.HumSetP.PreComfort HR8 AV8
Z009 Humidity setpoint - Comfort Real 50.0 %rh 0.0...100.0 R/W UnitSetP.HumSetP.Comfort HR9 AV9
Z010 CO2 air quality setpoint - Economy Real 900.0 ppm 0.0...9999.9 R/W
UnitSetP.AirQualitySetP.Econo
my
HR10 AV10
Z011 CO2 air quality setpoint - PreComfort Real 900.0 ppm 0.0...9999.9 R/W
UnitSetP.AirQualitySetP.PreCo
mfort
HR11 AV11
Z012 CO2 air quality setpoint - Comfort Real 900.0 ppm 0.0...9999.9 R/W
UnitSetP.AirQualitySetP.Comfor
t
HR12 AV12
Z013 VOC air quality setpoint - Economy Real 70.0 % 0.0...100.0 R/W
UnitSetP.VOC_QualitySetP.Eco
nomy
HR13 AV13
Z014 VOC air quality setpoint - PreComfort Real 60.0 % 0.0...100.0 R/W
UnitSetP.VOC_QualitySetP.Pre
Comfort
HR14 AV14
Z015 VOC air quality setpoint - Comfort Real 50.0 % 0.0...100.0 R/W
UnitSetP.VOC_QualitySetP.Co
mfort
HR15 AV15
Z016 Air flow setpoint - Economy Real 60.0 % MinFanPwr...100.0 R/W UnitSetP.AirFlwSetP.Economy HR16 AV16
Z017 Air flow setpoint - PreComfort Real 70.0 % MinFanPwr...100.0 R/W
UnitSetP.AirFlwSetP.PreComfor
t
HR17 AV17
Z018 Air flow setpoint - Comfort Real 80.0 % MinFanPwr...100.0 R/W UnitSetP.AirFlwSetP.Comfort HR18 AV18
Z019 Return air flow setpoint - Economy Real 60.0 MinFanPwr...100.0 R/W
UnitSetP.RetAirFlwSetP.Econo
my
HR19 AV19
Z020 Return air flow setpoint - PreComfort Real 60.0 MinFanPwr...100.0 R/W
UnitSetP.RetAirFlwSetP.PreCo
mfort
HR20 AV20
Z021 Return air flow setpoint - Comfort Real 60.0 MinFanPwr...100.0 R/W
UnitSetP.RetAirFlwSetP.Comfor
t
HR21 AV21
Z00c Index of the zone UInt 38 0...999 R/W GeneralMng.Zone_TZ HR22 PIV22
Z00c Writing of new day value enabled UInt 1...31 R/W DayIn HR23 PIV23
Z00c Writing of new month value enabled UInt 1...12 R/W MonthIn HR24 PIV24
Z00c Writing of new year value enabled UInt 0...99 R/W YearIn HR25 PIV25
Z00c Day of week UInt R DayOfWeek IR13 PIV13
Z00c Writing of new Hour value enabled UInt 0...24 R/W HourIn HR26 PIV26
Z00c Writing of new minute value enabled UInt min 0...59 R/W MinuteIn HR27 PIV27
Z00c Writing of new seconds value enabled UInt 0...59 R/W SecondIn HR28 PIV28
Z00c Scheduler active Bool R SchedActive DI1 BV42
Z00c Bool R
Scheduler_OnOffUnit.Scheduler
_1.DaySchedActive
DI2 BV43
Z00c Bool R
Scheduler_OnOffUnit.Scheduler
_1.VacationActive
DI3 BV44
Z00c Bool R
Scheduler_OnOffUnit.Scheduler
_1.SpecDayActive
DI4 BV45
Z00c Unit status currently active USInt R CurrUnitStatus IR14 PIV14
Z00d DInt 0...6 R/W
Scheduler_OnOffUnit.Scheduler
_1.Day
HR29 IV29
Z00d DInt 0...7 R/W
Scheduler_OnOffUnit.Scheduler
_1.CopyTo_Day
HR31 IV31
Z00d USInt 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.EnDayCopy
HR33 PIV33
Z00d Daily event enabled Bool 0...1 R/W Scheduler_OnOffUnit.Scheduler C1 BV50
