Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
30
Mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
_1.Event_Msk[0].Enabled
Z00d Starting time of the daily event (hour) USInt 0...23 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[0].Hours
HR34 PIV34
Z00d Starting time of the daily event (minute) USInt 0...59 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[0].Mins
HR35 PIV35
Z00d
Unit status of the daily event (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[0].UnitStatus
HR36 PIV36
Z00d Daily event enabled Bool 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[1].Enabled
C2 BV54
Z00d Starting time of the daily event (hour) USInt 0...23 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[1].Hours
HR37 PIV37
Z00d Starting time of the daily event (minute) USInt 0...59 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[1].Mins
HR38 PIV38
Z00d
Unit status of the daily event (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[1].UnitStatus
HR39 PIV39
Z00d Daily event enabled Bool 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[2].Enabled
C3 BV58
Z00d Starting time of the daily event (hour) USInt 0...23 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[2].Hours
HR40 PIV40
Z00d Starting time of the daily event (minute) USInt 0...59 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[2].Mins
HR41 PIV41
Z00d
Unit status of the daily event (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[2].UnitStatus
HR42 PIV42
Z00d Daily event enabled Bool 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[3].Enabled
C4 BV62
Z00d Starting time of the daily event (hour) USInt 0...23 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[3].Hours
HR43 PIV43
Z00d Starting time of the daily event (minute) USInt 0...59 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[3].Mins
HR44 PIV44
Z00d
Unit status of the daily event (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.Event_Msk[3].UnitStatus
HR45 PIV45
Z00d Messages to be displayed for daily events USInt R
Scheduler_OnOffUnit.Scheduler
_1.DaysSchedMsg
IR15 PIV15
Z00d USInt 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.SaveData
HR46 PIV46
Z00e Holiday period enabled Bool FALSE 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].Enabled
C5 BV68
Z00e First day of period USInt 1 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].StartDay
HR47 PIV47
Z00e First month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].StartMont
h
HR48 PIV48
Z00e Last day of period USInt 2 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].EndDay
HR49 PIV49
Z00e Last month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].EndMont
h
HR50 PIV50
Z00e
Unit status of the holiday period (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[0].UnitStatu
s
HR51 PIV51
Z00e Holiday period enabled Bool FALSE 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].Enabled
C6 BV74
Z00e First day of period USInt 1 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].StartDay
HR52 PIV52
Z00e First month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].StartMont
h
HR53 PIV53
Z00e Last day of period USInt 2 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].EndDay
HR54 PIV54
Z00e Last month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].EndMont
h
HR55 PIV55
Z00e
Unit status of the holiday period (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[1].UnitStatu
s
HR56 PIV56
Z00e Holiday period enabled Bool FALSE 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].Enabled
C7 BV80
Z00e First day of period USInt 1 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].StartDay
HR57 PIV57
Z00e First month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].StartMont
h
HR58 PIV58
Z00e Last day of period USInt 2 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].EndDay
HR59 PIV59
Z00e Last month of period USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].EndMont
h
HR60 PIV60
Z00e
Unit status of the holiday period (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT)
USInt 0 0...3 R/W
Scheduler_OnOffUnit.Scheduler
_1.VacationsSched[2].UnitStatu
s
HR61 PIV61
Z00e Messages to be displayed for vacation periods USInt R
Scheduler_OnOffUnit.Scheduler
_1.VacationsMsg
IR16 PIV16
Z00f Special day enabled Bool FALSE 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[0].Enabled
C8 BV87
Z00f Special day USInt 1 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[0].SpecialD
ay
HR62 PIV62
Z00f Special month USInt 1 1...12 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[0].SpecialM
onth
HR63 PIV63
Z00f
Unit status of the special day (0=OFF;
1=ECONOMY; 2=PRE-COMFORT; 3=COMFORT;
4=AUTO)
USInt 0 0...4 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[0].UnitStatu
s
HR64 PIV64
Z00f Special day enabled Bool FALSE 0...1 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[1].Enabled
C9 BV91
Z00f Special day USInt 1 1...31 R/W
Scheduler_OnOffUnit.Scheduler
_1.SpecDaysSched[1].SpecialD
ay
HR65 PIV65
