Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
33
B002 Hours counter cooling Bool 0...1 R/W HC_Cool_1.Res C20 BV555
B003 Cooling device - Manual value USInt 0...2 R/W Cool_1.Man HR109 PIV109
B004 Modulating cooling output - Manual mode analog
output
USInt 0...101 R/W CoolVlv.Man HR110 PIV110
- Cooling device 2nd step - Hardware value Bool R Cool_2.HW_Val DI51 BV236
- Cooling device 2nd step - Value Bool R Cool_2.Ctrl DI52 BV237
- Hours counter cooling 2nd step UDInt R HC_Cool_2.Hrs IR217 PIV217
B005 Hours counter cooling 2nd step UDInt
0
0...999999 R/W HC_Cool_2.MaintThrsh HR111 PIV111
B006 Hours counter cooling 2nd step Bool 0...1 R/W HC_Cool_2.Res C21 BV560
B007 Cooling device 2nd step - Manual value USInt 0...2 R/W Cool_2.Man HR113 PIV113
- Cooling request Real R Cooling_PID_Seq[4] IR219 AV219
B008 PID Cooling regulation - Proportional gain Real
5.0
-999.9...999.9 R/W DevCfg_PID_Seq_Cool[4].Kp HR114 AV114
B009 PID Cooling regulation - Integral time UInt 0...65535 R/W DevCfg_PID_Seq_Cool[4].Ti HR115 PIV115
B010 Minimum cooling request Real
2.0
% 0.0...100.0 R/W MainCoolMin HR116 AV116
B011 Time minimum ON ccooling device UInt
60
s 0...65535 R/W CoolMinOnT HR117 PIV117
B012 Time minimum OFF cooling device UInt
120
s 0...65535 R/W CoolMinOffT HR118 PIV118
B013 Time minimum ON ON cooling device UInt
300
s 0...65535 R/W CoolMinOnOnSameT HR119 PIV119
B014 Block cooling in mode USInt
0
0...2 R/W CoolDX_ResTyp HR120 PIV120
B015 Threshold to switch ON 1st cooling device Real
50.0
% 0.0...100.0 R/W ThrshOnCool_1 HR121 AV121
B016 Threshold to switch OFF 1st cooling device Real
0.0
% -999.9...999.9 R/W ThrshOffCool_1 HR122 AV122
B017 Threshold to switch ON 2nd cooling device Real
90.0
% 0.0...100.0 R/W ThrshOnCool_2 HR123 AV123
B018 Threshold to switch OFF 2nd cooling device Real
45.0
% -999.9...999.9 R/W ThrshOffCool_2 HR124 AV124
B019 Minimum cooling water coil Real
20.0
% 0.0...100.0 R/W MainCW_MinPID HR125 AV125
B020 Minimum cooling request UDInt
300
s 10...9999 R/W CoolVlvOpenTime HR126 PIV126
B021 Boost function setpoint in Cooling Real
50.0
% 0.0…100.0 R/W MainCoolMin_Boost HR1073 AV1448
6.6 COOL/HEAT menu in main menu
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
- Reverse device - Hardware value Bool R RevOut_1.HW_Val DI228 BV805
- Reverse device - Value Bool R RevOut_1.Ctrl DI65 BV250
- Hours counter reverse step UDInt R HC_Rev_1.Hrs IR264 PIV264
C001 Hours counter reverse step UDInt
0
0...999999 R/W HC_Rev_1.MaintThrsh HR322 PIV322
C002 Hours counter reverse step Bool 0...1 R/W HC_Rev_1.Res C37 BV808
C003 Reverse device - Manual value USInt 0...2 R/W RevOut_1.Man HR324 PIV324
C004 Modulating reverse output - Manual mode analog
output
USInt 0...101 R/W RevOutVlv.Man HR325 PIV325
- Reverse device 2nd step - Hardware value Bool R RevOut_2.HW_Val DI229 BV811
- Reverse device 2nd step - Value Bool R RevOut_2.Ctrl DI66 BV251
- Hours counter reverse 2nd step UDInt R HC_Rev_2.Hrs IR266 PIV266
C005 Hours counter reverse 2nd step UDInt
0
0...999999 R/W HC_Rev_2.MaintThrsh HR326 PIV326
C006 Hours counter reverse 2nd step Bool 0...1 R/W HC_Rev_2.Res C38 BV814
C007 Reverse device 2nd step - Manual value USInt 0...2 R/W RevOut_2.Man HR328 PIV328
- Cool/Heat device - Hardware value Bool R CoolHeat.HW_Val DI55 BV240
- Cool/Heat device - Value Bool R CoolHeat.Ctrl DI56 BV241
C038 Cool/Heat device - Manual value USInt 0...2 R/W CoolHeat.Man HR359 PIV359
- Heating request Real R Heating_PID_Seq[5] IR286 AV286
C039 PID Heating regulation - Proportional gain Real
5.0
0.0...999.9 R/W DevCfg_PID_Seq_Heat[5].Kp HR360 AV360
C040 PID Heating regulation - Integral time UInt
120
0...65535 R/W DevCfg_PID_Seq_Heat[5].Ti HR361 PIV361
C041 Minimum reverse request Real
0.0
% -999.9...999.9 R/W MainRevMin HR362 AV362
- Cooling request Real R Cooling_PID_Seq[5] IR287 AV287
C042 PID Cooling regulation - Proportional gain Real
5.0
0.0...999.9 R/W DevCfg_PID_Seq_Cool[5].Kp HR363 AV363
C043 PID Cooling regulation - Integral time UInt
120
0...65535 R/W DevCfg_PID_Seq_Cool[5].Ti HR364 PIV364
- Reverse antifreeze request Real % R RevW_AfreezeReq IR288 AV288
C044 Hot water setpoint Real
40.0
°C -999.9...999.9 R/W HW_Set HR187 AV187
C045 Heating water valve PID - Proportional (Kp) Real
5.0
0.0...999.9 R/W PID_HeatHW.Kp HR188 AV188
C046 Heating water valve PID - Integral (Ti) UInt
300
s 0...65535 R/W PID_HeatHW.Ti HR189 PIV189
C047 Minimum heating request Real
20.0
% 0.0...100.0 R/W MainHW_MinPID HR190 AV190
C048 Water heater antifreeze threshold Real
10.0
°C -999.9...999.9 R/W W_HeatFreezeSet HR191 AV191
C049 Minimum cooling request UDInt
300
s 10...9999 R/W CoolHeatVlvOpenTime HR365 PIV365
C050 Time minimum ON reverse device UInt
60
s 0...65535 R/W RevMinOnT HR367 PIV367
C051 Time minimum OFF reverse device UInt
180
s 0...65535 R/W RevMinOffT HR368 PIV368
C052 Time minimum ON ON reverse device UInt
300
s 0...65535 R/W RevMinOnOnSameT HR369 PIV369
C053 Threshold to switch ON 1st reverse device Real
40.0
% 0.0...100.0 R/W ThrshOnRev_1 HR370 AV370
C054 Threshold to switch OFF 1st reverse device Real
0.0
% -999.9...999.9 R/W ThrshOffRev_1 HR371 AV371
C055 Threshold to switch ON 2nd reverse device Real
90.0
% 0.0...100.0 R/W ThrshOnRev_2 HR372 AV372
C056 Threshold to switch OFF 2nd reverse device Real
60.0
% -999.9...999.9 R/W ThrshOffRev_2 HR373 AV373
C057 Antifreeze procedure minimum external
temperature
Real
0.0
°C -999.9...999.9 R/W AFreezeExtMinTemp HR231 AV231
C058 Antifreeze procedure maximum external
temperature
Real
6.0
°C -999.9...999.9 R/W AFreezeExtMaxTemp HR232 AV232
C059 Antifreeze procedure minimum time UInt
10
s 0...65535 R/W AFreezeHeatMinT HR233 PIV233
C060 Antifreeze procedure max time UInt
180
s 0...65535 R/W AFreezeHeatMaxT HR234 PIV234
C061 Antifreeze procedure minimum opening Real
20.0
% -999.9...999.9 R/W AfreezeHeatMin HR235 AV235
C062 Antifreeze procedure maximum opening Real
80.0
% -999.9...999.9 R/W AfreezeHeatMax HR236 AV236
C063 Boost function setpoint in heating Real
50.0
% 0.0…100.0 R/W MainHeatMin_Boost HR1074 AV1447
C064 Boost function setpoint in Cooling Real
50.0
% 0.0…100.0 R/W MainCoolMin_Boost HR1073 AV1448
