Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
36
F018 PID CO2 regulation - Proportional gain Real
10.0
-999.9...999.9 R/W DevCfg_PID_Seq_Hum[1].Kp HR293 AV293
F019 PID CO2 regulation - Integral time UInt
240
0...65535 R/W DevCfg_PID_Seq_Hum[1].Ti HR294 PIV294
- Absolute humidity Real g/s R AbsHum IR248 AV248
- Absolute humidity setpoint Real gH2O/
kg
R AbsHumSet IR249 AV249
F020 Bool
FALSE
0...1 R/W En_DeHumCool C35 BV769
- Dehumidification request Real % R DehumRegReq IR254 AV254
F021 PID CO2 regulation - Proportional gain Real
10.0
-999.9...999.9 R/W DevCfg_PID_Seq_Hum[2].Kp HR295 AV295
F022 PID CO2 regulation - Integral time UInt
240
0...65535 R/W DevCfg_PID_Seq_Hum[2].Ti HR296 PIV296
F023 Fresh air humidity check to enable
freecooling/freeheating
Real
5.0
gH2O/
kg
1.0...40.0 R/W DeltaAbsHum HR297 AV297
6.10 IN/OUT SETTINGS menu
ANALOG IN SET menu 6.10.1
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
- Analog input functions - Priority USInt R AI_ReadFnt[1].Prio IR336 PIV336
- Analog input functions - Hardware value Real °C R AI_ReadFnt[1].Read.Hw_Val IR337 AV337
Ga01 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[1].Ch HR760 IV760
Ga02 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[1].Param.Typ HR762 PIV762
Ga03 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[1].Param.Min_Val HR763 AV763
Ga04 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[1].Param.Max_Val HR764 AV764
Ga05 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[1].Param.Offset HR765 AV765
- Analog input functions - Priority USInt R AI_ReadFnt[2].Prio IR338 PIV338
- Analog input functions - Hardware value Real °C R AI_ReadFnt[2].Read.Hw_Val IR339 AV339
Ga06 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[2].Ch HR766 IV766
Ga07 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[2].Param.Typ HR768 PIV768
Ga08 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[2].Param.Min_Val HR769 AV769
Ga09 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[2].Param.Max_Val HR770 AV770
Ga10 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[2].Param.Offset HR771 AV771
- Analog input functions - Priority USInt R AI_ReadFnt[3].Prio IR340 PIV340
- Analog input functions - Hardware value Real °C R AI_ReadFnt[3].Read.Hw_Val IR341 AV341
Ga11 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[3].Ch HR772 IV772
Ga12 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[3].Param.Typ HR774 PIV774
Ga13 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[3].Param.Min_Val HR775 AV775
Ga14 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[3].Param.Max_Val HR776 AV776
Ga15 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[3].Param.Offset HR777 AV777
- Analog input functions - Priority USInt R AI_ReadFnt[4].Prio IR342 PIV342
- Analog input functions - Hardware value Real °C R AI_ReadFnt[4].Read.Hw_Val IR343 AV343
Ga16 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[4].Ch HR778 IV778
Ga17 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[4].Param.Typ HR780 PIV780
Ga18 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[4].Param.Min_Val HR781 AV781
Ga19 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[4].Param.Max_Val HR782 AV782
Ga20 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[4].Param.Offset HR783 AV783
- Analog input functions - Priority USInt R AI_ReadFnt[5].Prio IR344 PIV344
- Analog input functions - Hardware value Real bar R AI_ReadFnt[5].Read.Hw_Val IR345 AV345
Ga21 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[5].Ch HR784 IV784
Ga22 Analog input functions - Type USInt
43
0...50 R/W AI_ReadFnt[5].Param.Typ HR786 PIV786
Ga23 Analog input functions - Minimum value Real
0.0
bar -9999.9...9999.9 R/W AI_ReadFnt[5].Param.Min_Val HR787 AV787
Ga24 Analog input functions - Maximum value Real
45.0
bar -9999.9...9999.9 R/W AI_ReadFnt[5].Param.Max_Val HR788 AV788
Ga25 Analog input functions - Offset Real
0.0
bar -99.9...99.9 R/W AI_ReadFnt[5].Param.Offset HR789 AV789
- Analog input functions - Priority USInt R AI_ReadFnt[6].Prio IR346 PIV346
- Analog input functions - Hardware value Real °C R AI_ReadFnt[6].Read.Hw_Val IR347 AV347
Ga26 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[6].Ch HR790 IV790
Ga27 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[6].Param.Typ HR792 PIV792
Ga28 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[6].Param.Min_Val HR793 AV793
Ga29 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[6].Param.Max_Val HR794 AV794
Ga30 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[6].Param.Offset HR795 AV795
- Analog input functions - Priority USInt R AI_ReadFnt[7].Prio IR348 PIV348
- Analog input functions - Hardware value Real bar R AI_ReadFnt[7].Read.Hw_Val IR349 AV349
Ga31 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[7].Ch HR796 IV796
Ga32 Analog input functions - Type USInt
43
0...50 R/W AI_ReadFnt[7].Param.Typ HR798 PIV798
Ga33 Analog input functions - Minimum value Real
0.0
bar -9999.9...9999.9 R/W AI_ReadFnt[7].Param.Min_Val HR799 AV799
Ga34 Analog input functions - Maximum value Real
17.3
bar -9999.9...9999.9 R/W AI_ReadFnt[7].Param.Max_Val HR800 AV800
Ga35 Analog input functions - Offset Real
0.0
bar -99.9...99.9 R/W AI_ReadFnt[7].Param.Offset HR801 AV801
- Analog input functions - Priority USInt R AI_ReadFnt[8].Prio IR350 PIV350
- Analog input functions - Hardware value Real °C R AI_ReadFnt[8].Read.Hw_Val IR351 AV351
Ga36 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[8].Ch HR802 IV802
Ga37 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[8].Param.Typ HR804 PIV804
Ga38 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[8].Param.Min_Val HR805 AV805
Ga39 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[8].Param.Max_Val HR806 AV806
Ga40 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[8].Param.Offset HR807 AV807
- Analog input functions - Priority USInt R AI_ReadFnt[9].Prio IR352 PIV352
- Analog input functions - Hardware value Real °C R AI_ReadFnt[9].Read.Hw_Val IR353 AV353
Ga41 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[9].Ch HR808 IV808
Ga42 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[9].Param.Typ HR810 PIV810
Ga43 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[9].Param.Min_Val HR811 AV811
Ga44 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[9].Param.Max_Val HR812 AV812
