Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
43
Gd-
23
Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[23].Ch HR1094 IV1094
- Analog output functions - Priority USInt R AO_ReadFnt[24].Prio IR500 PIV500
- Analog output functions - Request Real R AO_ReadFnt[24].Hw_Val IR501 AV501
Gd-
24
Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[24].Ch HR1096 IV1096
6.11 SETTINGS menu in main menu
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
H001 Min supply temperature setpoint Real
16.0
°C -999.9...999.9 R/W SupplyMinSet HR298 AV298
H002 Max supply temperature setpoint Real
30.0
°C -999.9...999.9 R/W SupplyMaxSet HR299 AV299
H003 Setpoint minimum limit Real
5.0
°C -999.9...999.9 R/W SetMinLimit HR300 AV300
H004 Maximum setpoint value Real
30.0
°C -999.9...999.9 R/W SetMaxLimit HR301 AV301
- Compensation request Real % R PID_RegCompens IR262 AV262
H005 Regulation set point offset Real
5.0
-999.9...999.9 R/W RoomReg_SetP_Offs_Kp HR302 AV302
H006 Regulation set point offset: Integral time for room
regulation
UInt
300
0...65535 R/W RoomReg_SetP_Offs_Ti HR303 PIV303
- Compensation request Real % R ExtTempCompens IR263 AV263
H007 Min external temperature compensation in heating Real
10.0
°C -999.9...999.9 R/W MinHeatCompens HR304 AV304
H008 Max external temperature compensation in heating Real
0.0
°C -999.9...999.9 R/W MaxHeatCompens HR305 AV305
H009 Min external temperature compensation in cooling Real
30.0
°C -999.9...999.9 R/W MinCoolCompens HR306 AV306
H010 Max external temperature compensation in cooling Real
30.0
°C -999.9...999.9 R/W MaxCoolCompens HR307 AV307
H011 Cooling external temperature threshold Real
25.0
°C -999.9...999.9 R/W CoolExtTempThrsh HR308 AV308
H012 Heating external temperature threshold Real
10.0
°C -999.9...999.9 R/W HeatExtTempThrsh HR309 AV309
H013 Supply temp.: cooling/heating delay time UDInt
30
s 0...65535 R/W SupplyTemp_CoolHeatDT HR310 PIV310
H014 StandBy time UDInt
0
min 0...9999 R/W StandbyT HR312 PIV312
H015 Wake up time UDInt
180
min 10...9999 R/W WakeUpT HR314 PIV314
H016 Night kick hour UInt
1
0...23 R/W NightKickHour HR316 PIV316
H016 Night kick minute UInt
30
min 0...59 R/W NightKickMinute HR317 PIV317
H017 Enable freecooling/freeheating Bool
TRUE
0...1 R/W En_FreeCoolHeat C36 BV800
H018 Antistuck OFF time UInt
168
h 1...999 R/W AntiStuckOFF HR318 PIV318
H019 Antistuck ON time UInt
300
s 0...9999 R/W AntiStuckON HR319 PIV319
H020 Minimum design temperature Real
-45.0
°C -999.9...999.9 R/W MinDesignExtTemp HR320 AV320
H021 Maximum design temperature Real
55.0
°C -999.9...999.9 R/W MaxDesignExtTemp HR321 AV321
H022 Start-up unit mode Bool
FALSE
R/W Startup_Sequence C343 BV1430
H023 Boost function maximum time Int
60
s 0… 32767 R/W Boost_Time HR1072 IV1452
H025 Enable fix fresh damper position Bool
FALSE
R/W EN_FreshDampFixReq C381 BV1471
H026 fresh damper position percentage Real 100 % 0…100 R/W FreshDampFixReq HR1333 AV1668
Ha25 Fresh damper min value open Real % 0…100 ModulFreshDampMinVal HR1334 AV1669
Ha26 Fresh damper max value open Real % 0…100 ModulFreshDampMaxVal HR1335 AV1670
Hb25 Manaul management fresh damper Int 0 0…100 Modul_FreshDamper.Man HR1336 PI1671
H027 Enable external devices management Bool FALSE R/W En_ExtDevSign C382 BV1472
H028 Enable advanced PID managment Bool FALSE R/W En_PID_Modes C383 BV1473
H029 Modes set PID regulations PreHeat Real 5.0 -999.9...999.9 R/W PIDs_PreHeat.Comfort_Kp HR1152 AV1559
H030 Modes set PID regulations PreHeat Int 120 s 0...65535 R/W PIDs_PreHeat.Comfort_Ti HR1153 IV1560
H031 Modes set PID regulations PreHeat Real 5.0 -999.9...999.9 R/W PIDs_PreHeat.Economy_Kp
HR1112
AV1519
H032 Modes set PID regulations PreHeat Int 120 s 0...65535 R/W PIDs_PreHeat.Economy_Ti HR1113 IV1520
H033 Modes set PID regulations PreHeat Real 5.0 -999.9...999.9 R/W PIDs_PreHeat.Precomfort_Kp HR1132 AV1539
H034 Modes set PID regulations PreHeat Int 120 s 0...65535 R/W PIDs_PreHeat.Precomfort_Ti HR1133 IV1540
H035 Modes set PID regulations ReHeat Real 5.1 -999.9...999.9 R/W PIDs_ReHeat.Comfort_Kp HR1150 AV1557
H036 Modes set PID regulations ReHeat Int 121 s 0...65535 R/W PIDs_ReHeat.Comfort_Ti HR1151 IV1558
H037 Modes set PID regulations ReHeat Real 5.1 -999.9...999.9 R/W PIDs_ReHeat.Economy_Kp HR1110 AV1517
H038 Modes set PID regulations ReHeat Int 121 s 0...65535 R/W PIDs_ReHeat.Economy_Ti HR1111 IV1518
H039 Modes set PID regulations ReHeat Real 5.1 -999.9...999.9 R/W PIDs_ReHeat.Precomfort_Kp HR1130 AV1537
H040 Modes set PID regulations ReHeat Int 121 s 0...65535 R/W PIDs_ReHeat.Precomfort_Ti HR1131 IV1538
H041 Modes set PID regulations Heat Real 5.1 -999.9...999.15 R/W PIDs_Heat.Comfort_Kp HR1148 AV1555
H042 Modes set PID regulations Heat Int 121 s 0...65535 R/W PIDs_Heat.Comfort_Ti HR1149 IV1556
H043 Modes set PID regulations Heat Real 5.1 -999.9...999.9 R/W PIDs_Heat.Economy_Kp HR1108 AV1515
H044 Modes set PID regulations Heat Int 121 s 0...65535 R/W PIDs_Heat.Economy_Ti HR1109 IV1516
H045 Modes set PID regulations Heat Real 5.2 -999.9...999.9 R/W PIDs_Heat.Precomfort_Kp HR1128 AV1535
H046 Modes set PID regulations Heat Int 122 s 0...65535 R/W PIDs_Heat.Precomfort_Ti HR1129 IV1536
H047 Modes set PID regulations Cool Real 5.2 -999.9...999.9 R/W PIDs_Cool.Comfort_Kp HR1154 AV1561
H048 Modes set PID regulations Cool Int 122 s 0...65535 R/W PIDs_Cool.Comfort_Ti HR1155 IV1562
H049 Modes set PID regulations Cool Real 5.2 -999.9...999.9 R/W PIDs_Cool.Economy_Kp HR1114 AV1521
H050 Modes set PID regulations Cool Int 122 s 0...65535 R/W PIDs_Cool.Economy_Ti HR1115 IV1522
H051 Modes set PID regulations Cool Real 5.2 -999.9...999.9 R/W PIDs_Cool.Precomfort_Kp HR1134 AV1541
H052 Modes set PID regulations Cool Int 122 s 0...65535 R/W PIDs_Cool.Precomfort_Ti HR1135 IV1542
H053 PIDs_Rev_Cool.Comfort_Kp Real 5.2 -999.9...999.9 R/W PIDs_Rev_Cool.Comfort_Kp HR1158 AV1565
H054 PIDs_Rev_Cool.Comfort_Ti Int 122 s 0...65535 R/W PIDs_Rev_Cool.Comfort_Ti HR1159 IV1566
H055 PIDs_Rev_Cool.Economy_Kp Real 5.3 -999.9...999.9 R/W PIDs_Rev_Cool.Economy_Kp HR1118 AV1525
H056 PIDs_Rev_Cool.Economy_Ti Int 123 s 0...65535 R/W PIDs_Rev_Cool.Economy_Ti HR1119 IV1526
H057 PIDs_Rev_Cool.Precomfort_Kp Real 5.3 -999.9...999.9 R/W PIDs_Rev_Cool.Precomfort_Kp HR1138 AV1545
H058 PIDs_Rev_Cool.Precomfort_Ti Int 123 s 0...65535 R/W PIDs_Rev_Cool.Precomfort_Ti HR1139 IV1546
H059 Modes set PID regulations Rev Heat Real 5.3 -999.9...999.24 R/W PIDs_Rev_Heat.Comfort_Kp HR1156 AV1563
H060 Modes set PID regulations Rev Heat Int 123 s 0...65535 R/W PIDs_Rev_Heat.Comfort_Ti HR1157 IV1654
H061 Modes set PID regulations Rev Heat Real 5.3 -999.9...999.9 R/W PIDs_Rev_Heat.Economy_Kp HR1116 AV1523
H062 Modes set PID regulations Rev Heat Int 123 s 0...65535 R/W PIDs_Rev_Heat.Economy_Ti HR1117 IV1524
H063 Modes set PID regulations Rev Heat Real 5.3 -999.9...999.9 R/W PIDs_Rev_Heat.Precomfort_Kp HR1136 AV1543
H064 Modes set PID regulations Rev Heat Int 123 s 0...65535 R/W PIDs_Rev_Heat.Precomfort_Ti HR1137 IV1544
H065 Modes set PID regulations Heat Rec Real 5.4 -999.9...999.27 R/W PIDs_Heat_Rec.Comfort_Kp HR1160 AV1567
H066 Modes set PID regulations Heat Rec Int 124 s 0...65535 R/W PIDs_Heat_Rec.Comfort_Ti HR1161 IV1568
H067 Modes set PID regulations Heat Rec Real 5.4 -999.9...999.9 R/W PIDs_Heat_Rec.Economy_Kp HR1120 AV1527
H068 Modes set PID regulations Heat Rec Int 124 s 0...65535 R/W PIDs_Heat_Rec.Economy_Ti HR1121 IV1528
H069 Modes set PID regulations Heat Rec Real 5.4 -999.9...999.9 R/W PIDs_Heat_Rec.Precomfort_Kp HR1140 AV1547
H070 Modes set PID regulations Heat Rec Int 124 s 0...65535 R/W PIDs_Heat_Rec.Precomfort_Ti HR1141 IV1548
