Carel kVent - IN;OUT Settings - Analog Outputs

kVent – rel 3.1 – 22/06/2018
42
Gc87 Digital output functions - Channel DInt 0 0...70 R/W DO_ReadFnt[45].Ch HR1044 IV1044
Gc88 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[45].Logic C341 BV1990
- Digital output functions - Priority USInt R DO_ReadFnt[46].Prio IR453 PIV453
- Digital output functions - Status Bool R DO_ReadFnt[46].Hw_Val DI319 BV1992
Gc89 Digital output functions - Channel DInt 0 0...70 R/W DO_ReadFnt[46].Ch HR1046 IV1046
Gc90 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[46].Logic C342 BV1994
ANALOG OUT SET menu 6.10.4
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
- Analog output functions - Priority USInt R AO_ReadFnt[1].Prio IR454 PIV454
- Analog output functions - Request Real R AO_ReadFnt[1].Hw_Val IR455 AV455
Gd01 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[1].Ch HR1048 IV1048
- Analog output functions - Priority USInt R AO_ReadFnt[2].Prio IR456 PIV456
- Analog output functions - Request Real R AO_ReadFnt[2].Hw_Val IR457 AV457
Gd02 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[2].Ch HR1050 IV1050
- Analog output functions - Priority USInt R AO_ReadFnt[3].Prio IR458 PIV458
-: Analog output functions - Request Real R AO_ReadFnt[3].Hw_Val IR459 AV459
Gd03 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[3].Ch HR1052 IV1052
- Analog output functions - Priority USInt R AO_ReadFnt[4].Prio IR460 PIV460
- Analog output functions - Request Real R AO_ReadFnt[4].Hw_Val IR461 AV461
Gd04 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[4].Ch HR1054 IV1054
- Analog output functions - Priority USInt R AO_ReadFnt[5].Prio IR462 PIV462
- Analog output functions - Request Real R AO_ReadFnt[5].Hw_Val IR463 AV463
Gd05 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[5].Ch HR1056 IV1056
- Analog output functions - Priority USInt R AO_ReadFnt[6].Prio IR464 PIV464
- Analog output functions - Request Real R AO_ReadFnt[6].Hw_Val IR465 AV465
Gd06 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[6].Ch HR1058 IV1058
- Analog output functions - Priority USInt R AO_ReadFnt[7].Prio IR466 PIV466
- Analog output functions - Request Real R AO_ReadFnt[7].Hw_Val IR467 AV467
Gd07 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[7].Ch HR1060 IV1060
- Analog output functions - Priority USInt R AO_ReadFnt[8].Prio IR468 PIV468
- Analog output functions - Request Real R AO_ReadFnt[8].Hw_Val IR469 AV469
Gd08 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[8].Ch HR1062 IV1062
- Analog output functions - Priority USInt R AO_ReadFnt[9].Prio IR470 PIV470
- Analog output functions - Request Real R AO_ReadFnt[9].Hw_Val IR471 AV471
Gd09 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[9].Ch HR1064 IV1064
- Analog output functions - Priority USInt R AO_ReadFnt[10].Prio IR472 PIV472
- Analog output functions - Request Real R AO_ReadFnt[10].Hw_Val IR473 AV473
Gd10 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[10].Ch HR1066 IV1066
- Analog output functions - Priority USInt R AO_ReadFnt[11].Prio IR474 PIV474
- Analog output functions - Request Real R AO_ReadFnt[11].Hw_Val IR475 AV475
Gd11 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[11].Ch HR1068 IV1068
- Analog output functions - Priority USInt R AO_ReadFnt[12].Prio IR476 PIV476
- Analog output functions - Request Real R AO_ReadFnt[12].Hw_Val IR477 AV477
Gd12 Analog output functions - Channel DInt
0
0...60 R/W AO_ReadFnt[12].Ch HR1070 IV1070
Gd13 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[13].Ch HR1072 IV1070
- Analog output functions - Priority USInt R AO_ReadFnt[14].Prio IR480 PIV480
- Analog output functions - Request Real R AO_ReadFnt[14].Hw_Val IR481 AV481
Gd14 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[14].Ch HR1074 IV1074
- Analog output functions - Priority USInt R AO_ReadFnt[15].Prio IR482 PIV482
- Analog output functions - Request Real R AO_ReadFnt[15].Hw_Val IR483 AV483
Gd15 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[15].Ch HR1076 IV1076
- Analog output functions - Priority USInt R AO_ReadFnt[16].Prio IR484 PIV484
- Analog output functions - Request Real R AO_ReadFnt[16].Hw_Val IR485 AV485
Gd16 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[16].Ch HR1078 IV1078
- Analog output functions - Priority USInt R AO_ReadFnt[17].Prio IR486 PIV486
- Analog output functions - Request Real R AO_ReadFnt[17].Hw_Val IR487 AV487
Gd17 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[17].Ch HR1080 IV1080
- Analog output functions - Priority USInt R AO_ReadFnt[18].Prio IR488 PIV488
- Analog output functions - Request Real R AO_ReadFnt[18].Hw_Val IR489 AV489
Gd18 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[18].Ch HR1082 IV1082
- Analog output functions - Priority USInt R AO_ReadFnt[19].Prio IR490 PIV490
- Analog output functions - Request Real R AO_ReadFnt[19].Hw_Val IR491 AV491
Gd19 Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[19].Ch HR1084 IV1070
- Analog output functions - Priority USInt R AO_ReadFnt[20].Prio IR492 PIV492
- Analog output functions - Request Real R AO_ReadFnt[20].Hw_Val IR493 AV493
Gd-
20
Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[20].Ch HR1088 IV1088
- Analog output functions - Priority USInt R AO_ReadFnt[21].Prio IR494 PIV494
- Analog output functions - Request Real R AO_ReadFnt[21].Hw_Val IR495 AV495
Gd-
21
Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[21].Ch HR1090 IV1090
- Analog output functions - Priority USInt R AO_ReadFnt[22].Prio IR496 PIV496
- Analog output functions - Request Real R AO_ReadFnt[22].Hw_Val IR497 AV497
Gd-
22
Analog output functions - Channel DInt 0 0...60 R/W AO_ReadFnt[22].Ch HR1092 IV1092
- Analog output functions - Priority USInt R AO_ReadFnt[23].Prio IR498 PIV498
- Analog output functions - Request Real R AO_ReadFnt[23].Hw_Val IR499 AV499
