Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
44
H071 Modes set PID regulations Cool Rec Real 5.4 -999.9...999.9 R/W PIDs_Cool_Rec.Comfort_Kp HR1162 AV1569
H072 Modes set PID regulations Cool Rec Int 124 s 0...65535 R/W PIDs_Cool_Rec.Comfort_Ti HR1163 IV1570
H073 Modes set PID regulations Cool Rec Real 5.4 -999.9...999.9 R/W PIDs_Cool_Rec.Economy_Kp HR1122 AV1529
H074 Modes set PID regulations Cool Rec Int 124 s 0...65535 R/W PIDs_Cool_Rec.Economy_Ti HR1123 IV1530
H075 Modes set PID regulations Cool Rec Real 5.5 -999.9...999.9 R/W PIDs_Cool_Rec.Precomfort_Kp HR1142 AV1549
H076 Modes set PID regulations Cool Rec Int 125 s 0...65535 R/W PIDs_Cool_Rec.Precomfort_Ti HR1143 IV1550
H077 Modes set PID regulations Heat Rec Mix Real 5.5 -999.9...999.9 R/W PIDs_Heat_Rec_Mix.Comfort_Kp HR1164 AV1571
H078 Modes set PID regulations Heat Rec Mix Int 125 s 0...65535 R/W PIDs_Heat_Rec_Mix.Comfort_Ti HR1165 IV1572
H079 Modes set PID regulations Heat Rec Mix Real 5.5 -999.9...999.9 R/W PIDs_Heat_Rec_Mix.Economy_Kp HR1124 AV1531
H080 Modes set PID regulations Heat Rec Mix Int 125 s 0...65535 R/W PIDs_Heat_Rec_Mix.Economy_Ti HR1125 IV1532
H081 Modes set PID regulations Heat Rec Mix Real 5.5 -999.9...999.9 R/W PIDs_Heat_Rec_Mix.Precomfort_Kp HR1144 AV1551
H082 Modes set PID regulations Heat Rec Mix Int 125 s 0...65535 R/W PIDs_Heat_Rec_Mix.Precomfort_Ti HR1145 IV1552
H083 Modes set PID regulations Cool Rec Mix Real 5.5 -999.9...999.9 R/W PIDs_Cool_Rec_Mix.Comfort_Kp HR1166 AV1573
H084 Modes set PID regulations Cool Rec Mix Int 125 s 0...65535 R/W PIDs_Cool_Rec_Mix.Comfort_Ti HR1167 IV1574
H085 Modes set PID regulations Cool Rec Mix Real 5.6 -999.9...999.9 R/W PIDs_Cool_Rec_Mix.Economy_Kp HR1126 AV1533
H086 Modes set PID regulations Cool Rec Mix Int 126 s 0...65535 R/W PIDs_Cool_Rec_Mix.Economy_Ti HR1127 IV1534
H087 Modes set PID regulations Cool Rec Mix Real 5.6 -999.9...999.9 R/W PIDs_Cool_Rec_Mix.Precomfort_Kp HR1146 AV1553
H088 Modes set PID regulations Cool Rec Mix Int 126 s 0...65535 R/W PIDs_Cool_Rec_Mix.Precomfort_Ti HR1147 IV1554
6.12 UNIT CFG. menu in main menu
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
Unit configuration not allowed - Alarm status Bool R Al_UnitCfgError.Active DI1037 BV2068
I001 Recovery application code USInt 0 0...4 R/W AppCode_Rec HR83 PIV83
I001 Application heating code USInt 0 0...4 R/W AppCode_Heat HR84 PIV84
I001 Application cooling code USInt 0 0...2 R/W AppCode_Cool HR85 PIV85
I001 Application reverse code USInt 0 0...MaxAppCode_Rev R/W AppCode_Rev HR86 PIV86
I001 Application preheating code USInt 0 0...3 R/W AppCode_PreHeat HR87 PIV87
I001 Application reheater code USInt 0 0...3 R/W AppCode_ReHeat HR88 PIV88
I001 Application mixing damper code USInt 0 0...1 R/W AppCode_Eco HR89 PIV89
I001 Humidifier code USInt 0 0...3 R/W AppCode_Hum HR90 PIV90
I001 Board application code USInt 0 0...MaxAppCode_cpCOe R/W AppCode_cpCOe HR91 PIV91
I001 Application fan code USInt 0 0...3 R/W AppCode_Fan HR92 PIV92
I002 Recovery control type USInt 0 0...4 R/W AppRec_Special HR93 PIV93
I002 Heating control type USInt 0 0...11 R/W AppHeat_Special HR94 PIV94
I002 Cooling control type USInt 0 0...11 R/W AppCool_Special HR95 PIV95
I002 Reversible control type USInt 0 0...16 R/W AppCoolHeat_Special HR96 PIV96
I002 Preheat control type USInt 0 0...5 R/W AppPreHeat_Special HR97 PIV97
I002 Reheat control type USInt 0 0...5 R/W AppReHeat_Special HR98 PIV98
I002 Eco control type USInt 0 0...2 R/W AppMix_Special HR99 PIV99
I002 Supply fan regulation type USInt 0 0...9 R/W SupplyFanRegTyp HR100 PIV100
I002 Return fan regulation type USInt 0 0...9 R/W ExhFanRegTyp HR101 PIV101
I003 Run unit Bool FALSE 0...1 R/W UnitConfigured C15 BV543
I004 Run auto configuration function Bool 0...1 R/W RunAutoCfg_IO C16 BV544
I005 Enable thTune management Bool FALSE 0...1 R/W En_THTN_1 C17 BV545
I006 BMS address USInt 1 1...127 R/W BMS_Addr HR102 PIV102
I007 Scheduler type USInt 0 0...2 R/W TypScheduler HR103 PIV103
I008 Temperature regulation probe type USInt 1 0...2 R/W AppTempReg IR2 PIV2
I009 Regulation probe for humidier USInt 0 0...2 R/W AppHumReg HR104 PIV104
I012 Enable of Buzzer Bool 0...1 R/W En_Buzz C18 BV549
I014 Drive type internal/USB Byte 0...1 R/W DriveTyp HR105 PIV105
I015 Import-Export file name (EXPORT_XX) Int 0...99 R/W ImpExpFileName HR106 IV106
I017 Drive type internal/USB Byte 0...1 R/W DriveTyp HR105 PIV105
I018 Import-Export file name (EXPORT_XX) Int 0...99 R/W ImpExpFileName HR106 IV106
I020 Wipe memory Bool 0...1 R/W En_WipeMem C19 BV552
