6. PARAMETERS TABLE
The following tables show the parameters and values displayed by the terminal and the variables sent to supervisor.
kVent can be connected to various systems of supervision, in particular can be used the following communication protocols BMS on the
Ethernet port: Modbus® and BacNet™.
The Modbus® address is the address specified in the Modbus® frame.
BMS index meaning BacNet index meaning
IR Input Register AV Analog Value
HR Holding Register IV Integer Value
C Coil BV Binary Value
DI Discrete Input PIV Positive Integer Value
6.1 INFO menu in main mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
Y00a Supply temperature probe - Probe value Real °C
R SupplyTemp.ReadVal IR18 AV18
Y00a Temperature setpoint Real °C
R TempRegSetP IR1 AV1
Y00a Modulating heating output - Hardware value Real %
R HeatVlv.HW_Val IR19 AV19
Y00a Modulating reverse output - Hardware value Real %
R RevOutVlv.HW_Val IR20 AV20
Y00a Modulating cooling output - Hardware value Real %
R CoolVlv.HW_Val IR21 AV21
Y00a Modulating cooling/heating signal - Hardware value Real %
R
Modul_CoolHeat_NoRev.HW_V
al
IR22 AV22
Y00a Modulating heat recovery output - Hardware value Real
%
R HeatRecovery.HW_Val IR23 AV23
Y00a MixDampReq Real
%
R MixDampReq IR24 AV24
Y00a Modulating reheating output - Hardware value Real
%
R ReHeatVlv.HW_Val IR25 AV25
Y00h Supply air pressure probe - Probe value Real
Pa
R SupplyAirP.ReadVal IR74 AV74
Y00h Supply air flow Real
m3h
R SupplyAirFlow IR75 AV75
Y00h Modulating supply fan - Hardware value Real
%
R ModulSupplyFan.HW_Val IR76 AV76
Y00h Supply fan - Value Bool
R SupplyFan.Ctrl DI5 BV172
Y00i Exhaust air pressure probe - Probe value Real
Pa
R ExhAirP.ReadVal IR77 AV77
Y00i Return air flow Real
m3h
R ExhAirFlow IR78 AV78
Y00i Modulating return fan - Hardware value Real
%
R ModulExhFan.HW_Val IR79 AV79
Y00i Return fan - Value Bool
R ExhFan.Ctrl DI6 BV176
Y00j Supply temperature probe - Probe value Real
°C
R SupplyTemp.ReadVal IR18 AV18
Y00j Return temperature probe - Probe value Real
°C
R RetTemp.ReadVal IR80 AV80
Y00j External temperature probe - Probe value Real
°C
R ExtTemp.ReadVal IR81 AV81
Y00j Exhaust temperature probe - Probe value Real
°C
R ExhTemp.ReadVal IR82 AV82
Y00j Heating water temperature probe - Probe value Real
°C
R W_HeatCoilTemp.ReadVal IR83 AV83
Y00k Preheater water temperature probe - Probe value Real
°C
R W_PreHeatCoilTemp.ReadVal IR84 AV84
Y00k After preheating temperature probe - Probe value Real
°C
R AfterPreHeatCoilTemp.ReadVal IR85 AV85
Y00k thTune temperature value Real
°C
R Temp_THTN_1 IR86 AV86
Y00l thTune humidity value Real
%rh
R Hum_THTN_1 IR87 AV87
Y00l Supply humidity probe - Probe value Real
%rh
R SupplyHum.ReadVal IR88 AV88
Y00l Suction temperature probe - Probe value Real
%rh
R FreshAirHum.ReadVal IR89 AV89
Y00l Return CO2 sensor - Probe value Real
ppm
R RetAirCO2.ReadVal IR90 AV90
Y00l Return VOC sensor - Probe value Real
%
R RetAirVOC.ReadVal IR91 AV91
Y00p Digital input remote ON - Hardware value Bool
R RemoteOn.HW_Val DI13 BV198
Y00p Digital input remote ON - Input value Bool
R RemoteOn.ReadVal DI14 BV199
Y00p Digital input supply filter alarm - Hardware value Bool
R SupplyAlrmFilter.HW_Val DI15 BV200
Y00p Digital input supply filter alarm - Input value Bool
R SupplyAlrmFilter.ReadVal DI16 BV201
Y00p Digital input supply filter 2 alarm - Hardware value Bool
R SupplyAlrmFilter_2.HW_Val DI17 BV202
Y00p Digital input supply filter 2 alarm - Input value Bool
R SupplyAlrmFilter_2.ReadVal DI18 BV203
Y00p Digital input return filter alarm - Hardware value Bool
R ReturnAlrmFilter.HW_Val DI19 BV204
Y00p Digital input return filter alarm - Input value Bool
R ReturnAlrmFilter.ReadVal DI20 BV205
Y00p Digital Input door switch- Hardware value Bool
R Door_Switch.HW_Val DI1435 BV1457
Y00p Digital Input door switch-Input value Bool
R Door_Switch.ReadVal DI1436 BV1458
Y00p Digital Input recovery clogeed- Hardware value Bool
R Recovery_clogeed.HW_Val DI1433 BV1455
Y00p Digital Input recovery clogeed -Input value Bool
R Recovery_clogeed.ReadVal DI1434 BV1456
Y00q Digital input freeze alarm - Hardware value Bool
R FreezeHeat_Alrm.HW_Val DI21 BV206
Y00q Digital input freeze alarm - Input value Bool
R FreezeHeat_Alrm.ReadVal DI22 BV207
Y00q Digital input heating overload - Hardware value Bool
R DIN_AlHeat.HW_Val DI23 BV208
Y00q Digital input heating overload - Input value Bool
R DIN_AlHeat.ReadVal DI24 BV209
Y00q Digital input cooling alarm - Hardware value Bool
R CoolAlrm.HW_Val DI25 BV210
Y00q Digital input cooling alarm - Input value Bool
R CoolAlrm.ReadVal DI26 BV211
Y00q Digital input humidifier alarm - Hardware value Bool
R HumAlrm.HW_Val DI27 BV212
Y00q Digital input humidifier alarm - Input value Bool
R HumAlrm.ReadVal DI28 BV213
Y00q Digital input fire alarm - Hardware value Bool
R DIN_Fire.HW_Val DI29 BV214
Y00q Digital input fire alarm - Input value Bool
R DIN_Fire.ReadVal DI30 BV215
Y00q Digital input fan overload alarm - Hardware value Bool
R DIN_FanOvld.HW_Val DI31 BV216
Y00q Digital input fan overload alarm - Input value Bool
R DIN_FanOvld.ReadVal DI32 BV217
Y00r Digital input economy mode - Hardware value Bool
R DIN_Eco.HW_Val DI33 BV218
Y00r Digital input economy mode - Input value Bool
R DIN_Eco.ReadVal DI34 BV219
Y00r Digital input precomfort mode - Hardware value Bool
R DIN_PreComf.HW_Val DI35 BV220
Y00r Digital input precomfort mode - Input value Bool
R DIN_PreComf.ReadVal DI36 BV221
Y00r Digital input comfort mode - Hardware value Bool
R DIN_Comf.HW_Val DI37 BV222
