Page #27 background image
kVent – rel 3.1 – 22/06/2018
27
Mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
Y00r Digital input comfort mode - Input value Bool
R DIN_Comf.ReadVal DI38 BV223
Y00r Digital input Winter/Summer - Hardware value Bool
R WinSum.HW_Val DI39 BV224
Y00r Digital input Winter/Summer - Input value Bool
R WinSum.ReadVal DI40 BV225
Y00s Exhaust air damper - Hardware value Bool
R ExhAirDamp.HW_Val DI41 BV226
Y00s Exhaust air damper - Value Bool
R ExhAirDamp.Ctrl DI42 BV227
Y00s Serious alarm - Hardware value Bool
R SrsAlrm.HW_Val DI43 BV228
Y00s Serious alarm - Value Bool
R SrsAlrm.Ctrl DI44 BV229
Y00s Heating device - Hardware value Bool
R Heat_1.HW_Val DI45 BV230
Y00s Heating device - Value Bool
R Heat_1.Ctrl DI46 BV231
Y00s Cooling device - Hardware value Bool
R Cool_1.HW_Val DI47 BV232
Y00s Cooling device - Value Bool
R Cool_1.Ctrl DI48 BV233
Y00s Supply fan - Hardware value Bool
R SupplyFan.HW_Val DI49 BV234
Y00s Supply fan - Value Bool
R SupplyFan.Ctrl DI5 BV172
Y00t Return fan - Hardware value Bool
R ExhFan.HW_Val DI50 BV235
Y00t Return fan - Value Bool
R ExhFan.Ctrl DI6 BV176
Y00t Cooling device 2nd step - Hardware value Bool
R Cool_2.HW_Val DI51 BV236
Y00t Cooling device 2nd step - Value Bool
R Cool_2.Ctrl DI52 BV237
Y00t Heating device 2nd step - Hardware value Bool
R Heat_2.HW_Val DI53 BV238
Y00t Heating device 2nd step - Value Bool
R Heat_2.Ctrl DI54 BV239
Y00t Cool/Heat device - Hardware value Bool
R CoolHeat.HW_Val DI55 BV240
Y00t Cool/Heat device - Value Bool
R CoolHeat.Ctrl DI56 BV241
Y00t Recovery device - Hardware value Bool
R RecoveryPump.HW_Val DI57 BV242
Y00t Recovery device - Value Bool
R RecoveryPump.Ctrl DI58 BV243
Y00v Humidifier device - Hardware value Bool
R Hum.HW_Val DI59 BV244
Y00v Humidifier device - Value Bool
R Hum.Ctrl DI60 BV245
Y00v Preheater - Hardware value Bool
R PreHeaterPump.HW_Val DI61 BV246
Y00v Preheater - Value Bool
R PreHeaterPump.Ctrl DI62 BV247
Y00v Reheating device - Hardware value Bool
R ReHeat.HW_Val DI63 BV248
Y00v Reheating device - Value Bool
R ReHeat.Ctrl DI64 BV249
Y00v Heating device - Hardware value Bool
R Heat_1.HW_Val DI45 BV230
Y00v Reverse device - Value Bool
R RevOut_1.Ctrl DI65 BV250
Y00v Heating device 2nd step - Hardware value Bool
R Heat_2.HW_Val DI53 BV238
Y00v Reverse device 2nd step - Value Bool
R RevOut_2.Ctrl DI66 BV251
Y00x Heating 3point valve open - Hardware value Bool
R HeatVlv_Op.HW_Val DI77 BV262
Y00x Heating 3point valve open - Value Bool
R HeatVlv_Op.Ctrl DI78 BV263
Y00x Heating 3point valve close - Hardware value Bool
R HeatVlv_Cl.HW_Val DI79 BV264
Y00x Heating 3point valve close - Value Bool
R HeatVlv_Cl.Ctrl DI80 BV265
Y00x Coolng 3point valve open - Hardware value Bool
R CoolVlv_Op.HW_Val DI81 BV266
Y00x Coolng 3point valve open - Value Bool
R CoolVlv_Op.Ctrl DI82 BV267
Y00x Cooling 3point valve close - Hardware value Bool
R CoolVlv_Cl.HW_Val DI83 BV268
Y00x Cooling 3point valve close - Value Bool
R CoolVlv_Cl.Ctrl DI84 BV269
Y00y Reverse 3point valve open - Hardware value Bool
R CoolHeatVlv_Op.HW_Val DI85 BV270
Y00y Reverse 3point valve open - Value Bool
R CoolHeatVlv_Op.Ctrl DI86 BV271
Y00y Reverse 3point valve close - Hardware value Bool
R CoolHeatVlv_Cl.HW_Val DI87 BV272
Y00y Reverse 3point valve close - Value Bool
R CoolHeatVlv_Cl.Ctrl DI88 BV273
Y00y Eco 3point valve open - Hardware value Bool
R MixVlv_Op.HW_Val DI89 BV274
Y00y Eco 3point valve open - Value Bool
R MixVlv_Op.Ctrl DI90 BV275
Y00y Eco 3point valve close - Hardware value Bool
R MixVlv_Cl.HW_Val DI91 BV276
Y00y Eco 3point valve close - Value Bool
R MixVlv_Cl.Ctrl DI92 BV277
Y00z Heat recovery 3point valve open - Hardware value Bool
R HeatRecVlv_Op.HW_Val DI93 BV278
Y00z Heat recovery 3point valve open - Value Bool
R HeatRecVlv_Op.Ctrl DI94 BV279
Y00z Heat recovery 3point valve close - Hardware value Bool
R HeatRecVlv_Cl.HW_Val DI95 BV280
Y00z Heat recovery 3point valve close - Value Bool
R HeatRecVlv_Cl.Ctrl DI96 BV281
Y00z Preheating 3point valve open - Hardware value Bool
R PreHeatVlv_Op.HW_Val DI97 BV282
Y00z Preheating 3point valve open - Value Bool
R PreHeatVlv_Op.Ctrl DI98 BV283
Y00z Preheating 3point valve close - Hardware value Bool
R PreHeatVlv_Cl.HW_Val DI99 BV284
Y00z Preheating 3point valve close - Value Bool
R PreHeatVlv_Cl.Ctrl DI100 BV285
Y0a0 Reheating 3point valve open - Hardware value Bool
R ReHeatVlv_Op.HW_Val DI101 BV286
Y0a0 Reheating 3point valve open - Value Bool
R ReHeatVlv_Op.Ctrl DI102 BV287
Y0a0 Reheating 3point valve close - Hardware value Bool
R ReHeatVlv_Cl.HW_Val DI103 BV288
Y0a0 Reheating 3point valve close - Value Bool
R ReHeatVlv_Cl.Ctrl DI104 BV289
Y0a0 Recovery device - Hardware value Bool
R RecoveryStep1.HW_Val DI105 BV290
Y0a0 Recovery device - Value Bool
R RecoveryStep1.Ctrl DI106 BV291
Y0a0 Recovery device - Hardware value Bool
R RecoveryStep2.HW_Val DI107 BV292
Y0a0 Recovery device - Value Bool
R RecoveryStep2.Ctrl DI108 BV293
Y0ab Modulating reverse output - Hardware value Real
%
R RevOutVlv.HW_Val IR20 AV20
Y0ab Modulating heating output - Hardware value Real
%
R HeatVlv.HW_Val IR19 AV19
Y0ab Modulating cooling output - Hardware value Real
%
R CoolVlv.HW_Val IR21 AV21
Y0ab Modulating heat recovery output - Hardware value Real
%
R HeatRecovery.HW_Val IR23 AV23
Y0ab Modulating humidifier output - Hardware value Real
%
R ModulHum.HW_Val IR95 AV95
Y0ab Modulating reheating output - Hardware value Real
%
R ReHeatVlv.HW_Val IR25 AV25
Y0ac Modulating supply fan - Hardware value Real
%
R ModulSupplyFan.HW_Val IR76 AV76
Y0ac Supply fan - Value Bool
R SupplyFan.Ctrl DI5 BV172
Y0ac Modulating return fan - Hardware value Real
%
R ModulExhFan.HW_Val IR79 AV79
Y0ac Return fan - Value Bool
R ExhFan.Ctrl DI6 BV176
Y0ac Modulating preheating output - Hardware value Real
%
R ModulPreHeat.HW_Val IR96 AV96
Y0ac Modulating mixing damper output - Hardware value Real
%
R ModulMixDamp.HW_Val IR97 AV97
Y0ac Modulating cooling/heating signal - Hardware value Real
%
R
Modul_CoolHeat_NoRev.HW_V
al
IR22 AV22
Y0ad Supply fan - Value Bool
R SupplyFan.Ctrl DI5 BV172
