Page #28 background imageLoading...
Page #28 background image
kVent – rel 3.1 – 22/06/2018
28
Mask
code
Description Type Default UoM Range R/W Variable Name BMS BacNet
Y0ad Modulating supply fan - Hardware value Real
%
R ModulSupplyFan.HW_Val IR76 AV76
Y0ad
Ziehl Abegg supply fan - Actual speed [rpm] of the
Zhiel-Abegg fan
UInt
R
MB_Devices.FanSpeedInfo_ZA
_1.CurrSpeed_rpm
IR98 PIV98
Y0ad Ziehl Abegg supply fan - Maximum set speed UInt
R
MB_Devices.FanSpeedInfo_ZA
_1.MaxSpeed_rpm
IR99 PIV99
Y0ad Ziehl Abegg supply fan - Minimum set speed UInt
R
MB_Devices.FanSpeedInfo_ZA
_1.MinSpeed_rpm
IR100 PIV100
Y0ad
Ziehl Abegg supply fan electrical informations - DC
link voltage (V)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_1.DC_LinkV
IR101 PIV101
Y0ad
Ziehl Abegg supply fan electrical informations -
Supply voltage (peak voltage)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_1.LineV
IR102 PIV102
Y0ad
Ziehl Abegg supply fan electrical informations -
Fan level of speed controller (0-100%)
USInt
R
MB_Devices.FanElectricalInfo_Z
A_1.Modulation
IR103 PIV103
Y0ad
Ziehl Abegg supply fan electrical informations -
Motor input power (W)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_1.MotPwr
IR104 PIV104
Y0ae
Ziehl Abegg supply fan electrical informations -
Electronics temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_1.ElectronicTemp
IR105 AV105
Y0ae
Ziehl Abegg supply fan electrical informations -
IGBT temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_1.IGBT_temp
IR106 AV106
Y0ae
Ziehl Abegg supply fan electrical informations -
MCU temperature
Real
R
MB_Devices.FanElectricalInfo_Z
A_1.MCU_Temp
IR107 AV107
Y0ae
Ziehl Abegg supply fan electrical informations -
Motr temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_1.MotTemp
IR108 AV108
Y0af Return fan - Value Bool
R ExhFan.Ctrl DI6 BV176
Y0af Modulating return fan - Hardware value Real
%
R ModulExhFan.HW_Val IR79 AV79
Y0af
Ziehl Abegg return fan speed informations - Actual
speed [rpm] of the Zhiel-Abegg fan
UInt
R
MB_Devices.FanSpeedInfo_ZA
_2.CurrSpeed_rpm
IR109 PIV109
Y0af
Ziehl Abegg return fan speed informations -
Maximum set speed
UInt
R
MB_Devices.FanSpeedInfo_ZA
_2.MaxSpeed_rpm
IR110 PIV110
Y0af
Ziehl Abegg return fan speed informations -
Minimum set speed
UInt
R
MB_Devices.FanSpeedInfo_ZA
_2.MinSpeed_rpm
IR111 PIV111
Y0af
Ziehl Abegg return fan electrical info - DC link
voltage (V)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_2.DC_LinkV
IR112 PIV112
Y0af
Ziehl Abegg return fan electrical info - Supply
voltage (peak voltage)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_2.LineV
IR113 PIV113
Y0af
Ziehl Abegg return fan electrical info - Fan level of
speed controller (0-100%)
USInt
R
MB_Devices.FanElectricalInfo_Z
A_2.Modulation
IR114 PIV114
Y0af
Ziehl Abegg return fan electrical info - Motor input
power (W)
UInt
R
MB_Devices.FanElectricalInfo_Z
A_2.MotPwr
IR115 PIV115
Y0ag
Ziehl Abegg return fan electrical info - Electronics
temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_2.ElectronicTemp
IR116 AV116
Y0ag
Ziehl Abegg return fan electrical info - IGBT
temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_2.IGBT_temp
IR117 AV117
Y0ag
Ziehl Abegg return fan electrical info - MCU
temperature
Real
R
MB_Devices.FanElectricalInfo_Z
A_2.MCU_Temp
IR118 AV118
Y0ag
Ziehl Abegg return fan electrical info - Motr
temperature (°C)
Real
R
MB_Devices.FanElectricalInfo_Z
A_2.MotTemp
IR119 AV119
Y0ah Supply fan - Value Bool
R SupplyFan.Ctrl DI5 BV172
Y0ah Modulating supply fan - Hardware value Real
%
R ModulSupplyFan.HW_Val IR76 AV76
Y0ah
EBM supply fan speed info - Current speed in
[rpm] of the fan for Ebmpapst fan
UInt
rpm
R
MB_Devices.InfoSpeed_EBM_1
.CurrSpeed
IR120 PIV120
Y0ah
EBM supply fan speed info - Maximum admissible
speed: all read or speed in [rpm] settings are
limited to this value for Ebmpapst fan
UInt
rpm
R
MB_Devices.InfoSpeed_EBM_1
.MaxSpeed
IR121 PIV121
Y0ah
EBM supply fan electrical info - DC link voltage for
Ebmpapst fan
UInt
R
MB_Devices.ElectrInfo_EBM_1.
DC_Link_V
IR122 PIV122
Y0ah
EBM supply fan electrical info - DC link current for
Ebmpapst fan
UInt
R
MB_Devices.ElectrInfo_EBM_1.
DC_Link_A
IR123 PIV123
Y0ah
EBM supply fan electrical info - Current power in
[W] for Ebmpapst fan
UInt
W
R
MB_Devices.ElectrInfo_EBM_1.
CurrPower
IR124 PIV124
Y0ai
EBM supply fan electrical info - Internal circuit
temperature for Ebmpapst fan
UInt
°C
R
MB_Devices.ElectrInfo_EBM_1.
ElectrTemp
IR125 PIV125
Y0ai
Current rotation direction 0: Left; 1: Right; for
Ebmpapst fan
UInt
R MB_Devices.CurrRotDir_EBM_1 IR126 PIV126
Y0ai
EBM supply fan electrical info - Current modulation
level in [%] for Ebmpapst fan
UInt
%
R
MB_Devices.ElectrInfo_EBM_1.
CurrModulLev
IR127 PIV127
Y0aj Return fan - Value Bool
R ExhFan.Ctrl DI6 BV176
Y0aj Modulating return fan - Hardware value Real
%
R ModulExhFan.HW_Val IR79 AV79
Y0aj
EBM return fan speed info - Current speed in [rpm]
of the fan for Ebmpapst fan
UInt
rpm
R
MB_Devices.InfoSpeed_EBM_2
.CurrSpeed
IR128 PIV128
Y0aj
EBM return fan speed info - Maximum admissible
speed: all read or speed in [rpm] settings are
limited to this value for Ebmpapst fan
UInt
rpm
R
MB_Devices.InfoSpeed_EBM_2
.MaxSpeed
IR129 PIV129
Y0aj
EBM return fan electrical info - DC link voltage for
Ebmpapst fan
UInt
R
MB_Devices.ElectrInfo_EBM_2.
DC_Link_V
IR130 PIV130
Y0aj
EBM return fan electrical info - DC link current for
Ebmpapst fan
UInt
R
MB_Devices.ElectrInfo_EBM_2.
DC_Link_A
IR131 PIV131
Y0aj
EBM return fan electrical info - Current power in
[W] for Ebmpapst fan
UInt
W
R
MB_Devices.ElectrInfo_EBM_2.
CurrPower
IR132 PIV132
Y0ak
EBM return fan electrical info - Internal circuit
temperature for Ebmpapst fan
UInt
°C
R
MB_Devices.ElectrInfo_EBM_2.
ElectrTemp
IR133 PIV133
Y0ak
Current rotation direction 0: Left; 1: Right; for
Ebmpapst fan
UInt
R MB_Devices.CurrRotDir_EBM_2 IR134 PIV134
Y0ak
EBM return fan electrical info - Current modulation
level in [%] for Ebmpapst fan
UInt
%
R
MB_Devices.ElectrInfo_EBM_2.
CurrModulLev
IR135 PIV135
Y0ax
Current version of the application according to
standard - X version of the application
UInt
R CurrVer.X IR178 PIV178
Y0ax
Current version of the application according to
standard - Y version of the application
UInt
R CurrVer.Y IR179 PIV179
Y0ax
Current version of the application according to
standard - Z version of the application
UInt
R CurrVer.Z IR180 PIV180
Y0ax
Current version of the application according to
standard - Beta version enable
Bool
R CurrVer.IsBeta DI223 BV494
Y0ax
Current version of the application according to
standard - D version of the application
UInt
R CurrVer.D IR181 PIV181
Y0ax Application version UDInt
R GeneralMng.OsVersion[1] IR182 PIV182
