Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
47
Code
Description
on display
Reset
Action
Variable name
BMS
BacNet
A081 Return fan - Uin Low (FW 10) Auto reset Stop unit Al_UIN_LO_ZA_2 DI1081 BV1081
A082 Return fan - Uin High (FW 10) Auto reset Stop unit Al_UIN_HI_ZA_2 DI1082 BV1082
A083 Return fan - UZK low Auto reset Stop unit Al_UZK_Low_ZA_2 DI1083 BV1083
A084 Return fan - UZK high Auto reset Stop unit Al_UZK_High_ZA_2 DI1084 BV1084
A085 Return fan - IGBT fault Auto reset Stop unit Al_IGBTfault_ZA_2 DI1085 BV1085
A086 Return fan - Earth-GND fault Auto reset Stop unit Al_EarthGNDfault_ZA_2 DI1086 BV1086
A087 Return fan - Peak current error Auto reset Stop unit Al_PeakCurrent_ZA_2 DI1087 BV1087
A088 Return fan - Hall sensor error Auto reset Stop unit Al_HallSensor_ZA_2 DI1088 BV1088
A089 Return fan - Offline Auto reset Stop unit Al_Offline_EBM_2 DI1089 BV1089
A090 Return fan - Phase Failure User reset Stop unit Al_PhaseFault_EBM_2 DI1090 BV1090
A091 Return fan - Motor blocked User reset Stop unit Al_MotBlocked_EBM_2 DI1091 BV1091
A092 Return fan - Mains undervolt. User reset Stop unit Al_MainsUnderV_EBM_2 DI1092 BV1092
A093 Return fan - Mains overvoltage User reset Stop unit Al_MainsOverV_EBM_2 DI1093 BV1093
A094 Return fan - DC-link overvoltage User reset Stop unit Al_DClinkOverV_EBM_2 DI1094 BV1094
A095 Return fan - DC-link undervoltage User reset Stop unit Al_DClinkUnderV_EBM_2 DI1095 BV1095
A096 Return fan - Motor overheat User reset Stop unit Al_MotSuperHeating_EBM_2 DI1096 BV1096
A097 Return fan - Intern.circ.overheat User reset Stop unit Al_IntCircSuperHeat_EBM_2 DI1097 BV1097
A098 Return fan - Out stage overheat. User reset Stop unit Al_OutStageSuperHeat_EBM_2 DI1098 BV1098
A099 Return fan - Hall sensor error User reset Stop unit Al_HallSenErr_EBM_2 DI1099 BV1099
A100 Return fan - Communic. Error User reset Stop unit Al_CommunicationErr_EBM_2 DI1100 BV1100
A101 Return fan - Generic error User reset Stop unit Al_GenericErr_EBM_2 DI1101 BV1101
A102 Return fan - Out stage high temp. Auto reset Stop unit Al_OutStageHighTemp_EBM_2 DI1102 BV1102
A103 Return fan - Int.circ.high temp. Auto reset Stop unit Al_InternCircHighTemp_EBM_2 DI1103 BV1103
A104 Return fan - Motor high temp. Auto reset Stop unit Al_MotHighTemp_EBM_2 DI1104 BV1104
A105 Return fan - DC-link volt.low Auto reset Stop unit Al_DClinkV_Low_EBM_2 DI1105 BV1105
A106 Return fan - Lim.mains power Auto reset Stop unit Al_LimMainsPwr_EBM_2 DI1106 BV1106
A107 Return fan - Lim.mains current Auto reset Stop unit Al_LimMainsA_EBM_2 DI1107 BV1107
A108 Return fan - Brake mode Auto reset Stop unit Al_BrakeMode_EBM_2 DI1108 BV1108
A109 Return fan - Cable break Auto reset Stop unit Al_CableBreak_EBM_2 DI1109 BV1109
A110 Return fan - Ice protection Auto reset Stop unit Al_IceProtection_EBM_2 DI1110 BV1110
A111 Return fan - Heating: motor stop Auto reset Stop unit Al_HeatMotStopped_EBM_2 DI1111 BV1111
A112 Return fan - Speed under limit Auto reset Stop unit Al_SpeedUnderLim_EBM_2 DI1112 BV1112
A113 Return fan - DC-voltage high Auto reset Stop unit Al_DC_VoltageHigh_EBM_2 DI1113 BV1113
A114 Return fan - Supply volt.high Auto reset Stop unit Al_SupplyVoltageHigh_EBM_2 DI1114 BV1114
A115 Return fan - Line imp. High Auto reset Stop unit Al_LineImpHigh_EBM_2 DI1115 BV1115
A404 VOC air quality probe not working Auto reset Stop VOC regulation Al_RetAir_VOC_Prb DI1404 BV1404
A405 Supply filter 2 alarm Auto reset None Al_SupplyFilter_2 DI1405 BV1405
A406 Return filter alarm Auto reset None Al_ReturnFilter DI1406 BV1406
A407 Fresh air humidity probe not working Auto reset
Stop humidity check for
freecooling
Al_FreshAirHumPrb DI1407 BV1407
A408 Preheating coil maintenance required Auto reset None Al_PreheatCoilWorkHrsWarn DI1408 BV1408
A412 IEC humidifier maintenance required Auto reset None Al_HumIEC_WorkHrsWarn DI1412 BV1412
A413 Cool device maintenance required Auto reset None Al_CoolWorkHrsWarn DI1413 BV1413
A414 Cool device 2 maintenance required Auto reset None Al_Cool2_WorkHrsWarn DI1414 BV1414
A415 Heat device maintenance required Auto reset None Al_HeatWorkHrsWarn DI1415 BV1415
A416 Heat device 2 maintenance required Auto reset None Al_Heat2_WorkHrsWarn DI1416 BV1416
A417 Reverse device maintenance required Auto reset None Al_RevWorkHrsWarn DI1417 BV1417
A418 Reverse device 2 maintenance required Auto reset None Al_Rev2_WorkHrsWarn DI1418 BV1418
A422 Out of design temperature limits alarm Auto reset
Open mixing or stop
ventilation if not present
Al_OutDesignTemp DI1422 BV1422
A429 Recovery clogeed Auto reset Stop recovery Al_Recovery_clogeed DI1429 BV1429
A430 Door switch Auto reset Stop unit Al_Door_switch DI1430 BV1431
A431 Hepa 1 pressure probe alarm Auto reset None Al_HEPA_pressProb1 DI1441 BV1456
A432 Hepa 1 pressure probe alarm Auto reset None Al_HEPA_pressProb2 DI1442 BV1466
A433 Reversable coil alarm Auto reset Stop unit Al_Reversable DI1443 BV1467
A434 Generic external alarm Auto reset Stop unit Al_Input_generic DI1444 BV1468
A435 Hepa filter 1 Auto reset None Al_HEPA_Filter1 DI1445 BV1469
A436 Hepa filter 2 Auto reset None Al_HEPA_Filter2 DI1446 BV1470
