Par. Description Min. Max Default
Set-Point
C21 Minimum Set-point 1 limit -99 C22 min. probe
C22 Maximum Set-point 1 limit C21 999 max.probe
C23 Minimum Set-point 2 limit -99 C24 min. probe
C24 Maximum Set-point 2 limit C23 999 max.probe
Alarm Parameters (see pages 37 and 38)
P25 Low absolute alarm Set-Point -99 P26 min.probe
P26 High absolute alarm Set-Point P25 999 max.probe
P27 Alarm hysteresis 0.1 99.0 2.0
P28 Alarm Delay 0 120’ 0’
C29 Config. of dig. input 1 (C0 must be different from 6,7,8) 0 4 0
In case of alarm the status of relays depends on C31)
0 = non active input
1 = immediate alarm with automatic reset
2 = immediate alarm with manual reset
3 = delayed alarm (P28) with manual reset
4 = on/off of the control
C30 Digital Input 2 (IRDR only) 0 4 0
Options as for C29
C31 Status of the outputs in case of alarm
condition detected via digital input.
Options as for C10
55
Advanced set-up: list of parameters
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 55
