Page #58 background image
Par. Description Min. Max Default
C11 Output rotation: Modes 1, 2, 6,7,8 & models W&Z 0 7 0
0: no rotation
1: standard rotation
2: 2+2 rotation (compressor on outs 1 & 3)
3: 2+2 rotation (valve normal open)
4÷7: see technical manual
C12 time of PWM cycle 0,2’ 999’ 20’’
Probe parameters (see page 41)
C13 Probe type: 0=4-20, 1=0-20; 0=K T/c, 1= J T/c 0 1 0
NTC input: if C13=1 the instruments
displays NTC2 and controls on NTC1
P14 Probe calibration or offset -99 +99.9 0.0
C15 Min.value for scaling of analogue inputs -99 C16 0.0
C16 Max.value for scaling of analogue inputs C15 999 100
C17 Probe response time (noise filter) 1 14 5
C18 Temperature units: 0=°C, 1=°F 0 1 0
C19 2nd probe: NTC only, Mode 1 or 2 0 4 0
0 = no modification of the Standard Mode
1 = differential mode NTC1 - NTC2
2 = summer compensation
3 = winter compensation
4 = active compensation with Dead-Band
54
Advanced set-up: list of parameters
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 54
