Carel universal infrared series User Manual

73
IRDR TE & IRDR V: Collegamenti / Connections
OUT 1
PROBE
DIG.2 COM. DIG.1
1 2 3
c
220
240V
0
POWER
24V
SERIAL
LINK
~
~
(vedi/ see fig. 15)
220
240V
OUT 1
PROBE
DIG.2 COM. DIG.1
0
POWER
NTC
p2 p1
1 2 3
c
~
Versione TE, alimentazione
220÷240 Vac/Vdc, ingresso
NTC
Version W, power supply
220÷240Vac/Vdc, NTC input
Versione V, alimentazione
24÷240 Vac/Vdc, ingresso
NTC o Pt100 o Tc J/K o V/I
Version V, power supply
24÷240Vac/Vdc, NTC or
Pt100 or J/K Tc or V/I input
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 73
