Carel universal infrared series User Manual

74
IRDR W & IRDR Z: Collegamenti / Connections
OUT 1
PROBE
DIG.2 COM. DIG.1
1 2 3
c
OUT 2
c
220
240V
0
POWER
24V
SERIAL
LINK
~
~
(vedi/ see fig. 15)
Versione W, alimentazione
24÷230 Vac/Vdc, ingresso
NTC o Pt100 o Tc J/K o V/I
Version W, power supply
24÷230Vac/Vdc, NTC or
Pt100 or J/K Tc or V/I input
Versione Z, alimentazione
12÷24 Vac/Vdc, ingresso
NTC o Pt100 o Tc J/K o
V/I
Version Z, power supply
12÷24Vac/Vdc, NTC or
Pt100 or J/K Tc or V/I
input
PROBE
DIG.2 COM. DIG.1
1 2 3
SERIAL
LINK
OUT 1
OUT 3
OUT 2
OUT 4
POWER
12-24 V
3 VA
c c
- +
(vedi/ see fig. 15)
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 74
