Carel universal infrared series User Manual

75
IRDR A: Collegamenti / Connections
PROBE
DIG.2 COM. DIG.1
1 2 3
SERIAL
LINK
OUT 1
OUT 3
OUT 2
OUT 4
POWER
12-24 V
3 VA
- +
+ -
+ - + -
+ -
com.
(vedi/ see fig. 15)
Versione A, alimentazione
12÷24 Vac/Vdc, ingresso
NTC o Pt100 o Tc J/K o V/I
Version A, power supply
12÷24Vac/Vdc, NTC or
Pt100 or J/K Tc or V/I input
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 75

Carel universal infrared series Specifications

General

Brand	Carel
Model	universal infrared series
Category	Controller
Language	English
