29
▲
▲
To conclude the RESET procedure, press ; to go back to
the TARIFF SELECTION menu, press .
The reset procedure allows the user to choose
among the following different choices:
ALL: reset of all the energy meters (imported/
exported energies);
TOTAL + : reset of the imported energy me-
ters (+kWh, +kvarh);
TOTAL - : reset of the exported energy meters (-kWh, -kvarh);
PARTIAL + : reset of the partial imported energy meters
(+kWh, +kvarh);
PARTIAL - : reset of the partial exported energy meters
(-kWh, -kvarh).
■
HARMONIC ANALYSIS
This function enables the display of
the windows relating to the harmonic
analysis.
Press to enter the menu; then,
use the and keys to select
the phase where you want to enable
the harmonic analysis. The key
allows the user to enable (ON) or
disable (OFF) the displaying (the
function is cyclical: ON-OFF-ON).
To go back to the main menu, press
.
Outputs / Other settings
Multi tariff
27
37
Alarm parameters
33
