23
3- press the key again; the end-
tariff hour is highlighted;
4- press the key again; the
HOURS box will appear on the lower
part of the display; now you can
choose the hours - e.g. 8 - by means
of the and keys.
5- press the key again; the end
tariff minutes will be highlighted;
6-press the key again: the MIN-
UTES box will appear on the lower
part of the display; now you can set
the minutes - e.g. 10 - by means of the
and and keys.
7-after the confirmation of the last set-
ting, press and you are back to the
sel
ection of the first "trf" parameter
you have highlighted.
The starting hour of the following line
becomes equal to the end hour you
have just selected. Only when the trf
parameter is highlighted, you can scroll
the parameters and modify them:
use the key to access to the
parameter; use the key to move
from left to right and the key to
move from right to left.
8- Press to exit the programming
of the parameters of the relevant row
(no boxes are to be highlighted);
9- press and to select one
of the other programming lines; the
pointer on the right shows the line
where the user can modify the pa-
rameters (points from 1 to 7).
1.2..
..2.1
1.2..
..2.1
1.2..
..2.1
Energy Meters Management
Diagrams
21
22
28
Reset of the energy meters
28
Proceed with the same
principle for the follow-
ing rows. To exit any
item use always .
