5
To begin with
Displaying of the harmonic analysis
9
6
Index
2
Go to the page where the subject written
on the bottom of the current page starts.
This symbol indicates a particularly important
subject or information.
This symbol indicates that more details are
given on the current subject.
We suggest you to keep the original pack-
ing in case it is necessary to return the
instrument to our Technical Service De-
partment. In order to achieve the best results
with your instrument, we recommend you
to read this instruction manual carefully.
Main programming parameters
Programming of the password
Selection of the electrical system
Programming of the CT ratio (up to 30,000 A)
Programming of the VT ratio (up to 600kV)
Selection of the variables for the MIN / MAX detection
Programming of the calculation of the integration time period
Tariff management
Harmonic analysis enabling
Clock adjustment (if present)
Programming of the pulse output (if present)
Programming of the serial and analogue outputs (if present)
Programming of the digital filter.
