45
▲
▲
❑
Mounting
Insert the instrument (holding
its front) and fasten it (from the
back) by fixing the two lateral
brackets (1) (supplied with the
instrument) to the appropriate
location (2), using the two
screws (3) supplied with the
instrument.
3
1
2
❑
Overall dimensions and panel cut-out
Installation
Installation
43
51
Power supply modules
49
44
