CARLO GAVAZZI WM3-96 - PROGRAMMING User Manual

▲
▲
58
Technical features
53
Digital outputs
60
56
64
Three-phase connections
RANGE (IMPEDANCE):
• AV5:
58V/100V (>500kΩ) - 1ADC ( ≤ 0.3VA)
58V/100V (>500kΩ) - 5ADC ( ≤ 0.3VA)
240V/415V (>500kΩ) - 1ADC ( ≤ 0.3VA)
240V/415V (>500kΩ) - 5ADC ( ≤ 0.3VA)
• AV7:
100/170V (>500kΩ) - 1ADC (0.3VA)
110/170V (>500kΩ) - 5ADC (0.3VA)
400/690V (>500kΩ) - 1ADC (0.3VA)
400/690V (>500kΩ) - 5ADC (0.3VA)
FREQUENCY RANGE: 40 to 440 Hz
■ Overload protection
• Continuous: voltage/current
AV5: 300VLN/520VLL/6A;
AV7: 480VLN/830VLL/6A
• For 1s: voltage/current
AV5: 600VLN/1040VLL/120A;
AV7: 960VLN/1660VLL/120A
■ Keypad
Four keys: to enter the programming phase and confirm
the password, “UP” and “DOWN” to program the
values / select the functions and scroll the pages, for
special functions.
■ Output specifications
ANALOGUE OUTPUTS (on request):
• Number of outputs: up to 4 (on request)
• Accuracy: ±0.2% f.s.; (@ 25°C ±5°C, R.H. ≤ 60% non-
condensing)
• Range: 0 to 20mADC, 0 to ±20mADC,
