61
Technical features
59
56
64
Serial output
ALARMS: (on request)
Number of outputs: up to four, independent
Alarm type: up alarm, down alarm, up alarm with latch, down
alarm with latch, phase asymmetry, phase loss, neutral loss.
Set-point adjustment: 0 to 100% of the electrical scale
Hysteresis: 0 to 100% of the electrical scale
On time delay: 0 to 255s
Relay status: selectable, normally close or normally open.
Output type: relay, SPDT; AC 1-8A, 250VAC; DC 12-5A,
24VDC; AC 15-2.5A, 250VAC; DC 13-2.5A, 24VDC.
Min. response time: 150ms, filter excluded, set-point on-
time delay: 0
Insulation: 4000 Vrms output to measuring inputs,
4000 Vrms output to power supply input.
Note: the outputs can be either relay type or open collector
type (for the latter type of output see the features mentioned
in the PULSE OUTPUT paragraph).
Software functions
PASSWORD: numeric code of max 3 digits;
2 protection levels of the programming data
1st level - Password "0", no protection.
2nd level - Password from 1 to 499, all data are protected.
MEASUREMENT SELECTION: see the relevant table.
TRANSFORMER RATIO:
for CT up to 30,000A; for VT up to 600kV.
SCALING FACTOR:
Operating mode:
Electrical scale: compression/expansion of the input scale to
be connected to up to 4 analogue outputs.
Operating range: programmable within the whole measuring
range.
