Electrical diagrams
Serial connection
51
52
55
Additional errors
57
Direct connection
(4-wire system)
❑
Three-phase, 4 wires
- Unbalanced load
CT connection
(4-wire system)
CT connections
(4-wire system)
CT and VT connections
(4-wire system)
❑
Three phase, Balanced load
