Page | 35
Carlson Software
• Select Scan Buon: Allows you to select from P1, P2, or P3 as the RFID
scan buon. While the RFID applicaon is running, these override
what is specied in the Keypad Control Panel. If the RFID Connector
has P1 set as the scan buon, the Keypad Control Panel will show P1
as blank. This should not be changed from within the Keypad Control
Panel while the RFID Connector is running. Once the RFID Connector
closes, the scan buon reverts back to what it was just before the
RFID Connector launched.
• Beep on good/bad read: A sound plays when a tag is read. A dierent
sound plays when the me has elapsed and no tag was read.
• Startup RFID Connector on bootup: The RFID Connector soware will
automacally start when the device boots.
• Startup RFID Connector Minimized: The RFID Connector soware will
automacally be minimized when it is started.
• Use copy/paste buer: When this is set, the RFID data (somemes
including prex/sux data) is placed in the copy buer, and then a
“Ctrl-V” is simulated to paste the data wherever the user has focus.
Cauon: The data is le in the copy buer, so if sensive data is being
scanned, use “individual keystrokes”. This method is much more
snappy.
• Use individual keystrokes: When this is set, every character (including
prex/sux data) is sent as individual keystrokes.
• Scan opon: This is a way to test your setup. When pressed, the Scan
Data box is cleared and an RFID scan is iniated. An alternave is to
put the cursor in the Scan Data box, and then press the buon that is
assigned as the scan buon (P1, P2, or P3).
Reading a Tag
Open a document to receive the tag data and put a cursor in the proper
locaon. For best read performance, hold the RT4 with the display facing
you, and the tag directly away from the back of the RT4. The RFID reader
is internal and roughly 2” to the right of the camera when looking at the
back of the RT4. The best orientaon is portrait or landscape with RT4
orthogonal or normal to the tag.
