Carpenter Model 860 Material Coiling Unit
Carpenter Model 860 Material Coiling Unit • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 05/09/2024 Page 25
Figure 11: Adjustable Tube Assembly in the Up (Stop) Position (Removing Finished Coil)
6. The operator may then adjust the “RESTART DWELL” to a setting that provides ample
time to remove the formed material coil from the Model 860 coiling bowl without
excessive additional wait time before the start of the next cycle.
7. With the settings correctly adjusted, begin processing material by pressing the RUN
button on the material processing machine.
