Carrier 30MP - Calibration and Rotation; Sensor Calibration; Chiller Rotation Methods

Appendix C: 30MP Multi-chiller Points/Properties
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
34
Point Name/Description
Range
Sensor Calibration
Leaving Load Water Temperature –
The current leaving load water temperature. R: __°F
Leaving Source Temp Sensor Calibration
– A calibration offset value that allows you to
adjust the local leaving source water temperature sensor to match a calibrated standard
that is measuring the temperature in the same location.
D:
R:
0°F
-9.9 to 10°F
Outdoor Air Temperature
– The current outdoor air temperature. R: __°F
Outdoor Air Temp Sensor Calibration
– A calibration offset value you can adjust so the
outdoor air temperature sensor matches a calibrated standard that measures the
temperature in the same location.
D:
R:
0°F
-9.9 to 10°F
Space Relative Humidity –
Displays the current value of relative humidity sensor, if
present. Applicable if
Relative Humidity Source
is not set to
N/A
.
R: __%
Space RH Sensor Calibration
– A calibration offset value that allows you to adjust the
space relative humidity sensor to match a calibrated standard that is measuring the
humidity in the same location.
D:
R:
0%rh
-15 to 15%rh
Chiller Rotation
Rotation Method Selector - Equal Size
Daily
– Rotates the lead chiller daily at a specified time period.
Weekly
– Rotates the lead chiller weekly on a specified day and time period.
Monthly
– Rotates the lead chiller monthly on a specified day and time period.
Manual Rotation
– Manually rotates the lead chiller when the operator commands it.
Runtime
– Rotates the lead chiller after it reaches a specified number of runtime hours.
Runtime Equalization
– Rotates the lead chiller when all chillers are on and lead chiller
runtime > lag chiller runtime.
D:
R:
Runtime Equalization
Daily
Weekly
Monthly
Manual Rotation
Runtime
Runtime Equalization
Specify details of the selected Rotation Method.
Method
Enter...
Daily
time of day to rotate the lead chiller
NOTE Enter the time of day below in Defined
Time for Rotation:.
Weekly
day of the week to rotate the lead chiller
D:
R:
Wednesday
Sunday to
Saturday
Monthly
day of the month to rotate the lead chiller
monthly
D:
R:
1
1 to 31
Manual Rotation
manually rotates the lead chiller
D:
R:
Do not Rotate
Rotate
Do Not Rotate
Runtime
number of runtime hours before rotating the
lead chiller
D:
R:
360 hrs
200-9999 hrs
Runtime
Equalization
rotates the lead chiller when all chillers are on
and lead chiller runtime > lag chiller runtime.
