Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
159 OF 168
159
6
rpm
0 to 8000
3000
rpm
Motor Nameplate RPM
7
rlkw
0 to 5600
1500
kW
Motor Nameplate KW
8
skipfrq1
0 to 102
30
Hz
Skip Frequency 1
9
skipfrq2
0 to 102
30
Hz
Skip Frequency 2
10
skipfrq3
0 to 102
30
Hz
Skip Frequency 3
11
skipband
0 to 102
0
Hz
Skip Frequency Band
12
ramp_inc
5 to 60
30
sec
Increase Ramp Time
13
ramp_dec
5 to 60
30
sec
Decrease Ramp Time
14
lvim_th
1 to 10
10
%
Line Voltage Imbalance%
15
lvim_per
1 to 10
10
sec
Line Volt Imbalance Time
16
lcim_th
5 to 40
40
%
Line Current Imbalance%
17
lcim_per
1 to 10
10
sec
Line Current Imbal Time
18
mcim_th
5 to 40
40
%
Motor Current Imbalance
19
mcim_per
1 to 10
10
sec
Motor Current Imbal Time
20
scycd_en
DSABLE_ENABLE
DSABLE
-
Single Cycle Dropout
21
pwm_freq
0 to 1
0
-
PWM Switch Frequency
22
blank
-
-
-
2KHz=0, 4KHz=1
23
unit_byp
DSABLE_ENABLE
DSABLE
-
Unit Bypass Option
24
syst_byp
DSABLE_ENABLE
DSABLE
-
System Bypass Option
25
com_tout
0 to 255
10
sec
Communication Timeout
26
res_def
NO_YES
NO
-
Restore Defaults
*Depends on the selected language (English by default).
GENCONF - General
Name
Range
Default
Unit
Displayed text*
1
min_off
1 to 15
3
min
Stop to Start Delay

Carrier SmartVu control Specifications

General

Brand	Carrier
Model	SmartVu control
Category	Control Panel
Language	English
