Carrier Touch Pilot - Modes Menu Parameters; Setpoint Menu Parameters

18
Run Times Menu – RUNTIME (continued)
No. Name Status Unit Displayed text* Description
10 hr_cpum2 - hour Cooler Pump #2 Hours Operating hours, evaporator pump 2
11 hr_hpum1 - hour Condenser Pump #1 Hours Operating hours, condenser pump
12 hr_hpum2 - hour Condenser Pump #2 Hours Not applicable to this unit
*Depends on the selected language (English by default).
Modes Menu – MODES
No. Name Status Unit Displayed text* Description
1 m_delay no/yes - Start Up Delay In Eect Start-up delay in eect
2 m_2stpt no/yes - Second Setpoint In Use Second setpoint in use
3 m_reset no/yes - Reset In Eect Setpoint reset active
4 m_demlim no/yes - Demand limit active Demand limit active
5 m_ramp no/yes - Ramp Loading Active Ramp loading active
6 m_pmprot no/yes - Cooler Pump Rotation Evaporator pump rotation
7 m_pmpper no/yes - Pump Periodic Start Pump periodic start active
8 m_night no/yes - Night Low Noise Active Night low noise active
9 m_slave no/yes - Master Slave Active Master/Slave mode active
10 m_autoc no/yes - Auto Changeover Active Not applicable to this unit
11 m_lowEwt no/yes - Heating Low EWT Lockout Heating low EWT lockout
12 m_cpmpro no/yes - Condenser Pump Rotation Not applicable to this unit
13 m_cpmppr no/yes - Cond Pump Periodic Start Condenser pump periodic start
14 m_ice no/yes - Ice Mode In Eect Ice storage mode active (EMM option)
15 m_sst_a no/yes - Low Suction Circuit A Low suction, circuit A
16 m_sst_b no/yes - Low Suction Circuit B Low suction, circuit B
17 m_sst_c no/yes - Low Suction Circuit C Not applicable to this unit
18 m_map_a no/yes - Map compressor Circuit A Compressor mapping, circuit A
19 m_map_b no/yes - Map compressor Circuit B Compressor mapping, circuit B
20 m_map_c no/yes - Map compressor Circuit C Not applicable to this unit
21 m_hp_a no/yes - High Pres Override Cir A High pressure override, circuit A
22 m_hp_b no/yes - High Pres Override Cir B High pressure override, circuit B
23 m_hp_c no/yes - High Pres Override Cir C Not applicable to this unit
*Depends on the selected language (English by default).
Setpoint Menu – SETPOINT
No. Name Status Default Unit Displayed text* Description
1 csp1 -5 to 32 20 °C Cooling Setpoint 1 Cooling setpoint 1 (used during occupied periods)
2 csp2 -5 to 32 20 °C Cooling Setpoint 2 Cooling setpoint 2 (used during unoccupied periods)
3 ice_sp -29 to 26 6.7 °C Cooling Ice Setpoint Ice storage setpoint
4 cramp_sp 0.1 to 11.1 0.6 ^C Cooling Ramp Loading Cooling ramp loading setpoint (rate at which the water
temperature may change within one minute in Cooling)
5 hsp1 35 to 85 70 °C Heating Setpoint 1 Heating setpoint 1 (used during occupied periods)
6 hsp2 35 to 85 70 °C Heating Setpoint 2 Heating setpoint 2 (used during unoccupied periods)
7 hramp_sp 0.1 to 11.1 0.6 ^C Heating Ramp Loading Heating ramp loading setpoint (rate at which the water
temperature may change within one minute in Heating)
8 cauto_sp 3.9 to 50 23.9 °C Cool Changeover Setpt Not applicable to this unit
9 hauto_sp 0 to 46 17.8 °C Heat Changeover Setpt Not applicable to this unit
10 w_sct_sp 26.7 to 60 35 °C Water Val Condensing
Stp
Water valve condensing setpoint
11 lim_sp1 0 to 100 100 % Switch Limit Setpoint 1 Demand limit setpoint 1
12 lim_sp2 0 to 100 100 % Switch Limit Setpoint 2 Demand limit setpoint 2
13 lim_sp3 0 to 100 100 % Switch Limit Setpoint 3 Demand limit setpoint 3
*Depends on the selected language (English by default).
