Carrier Touch Pilot - Outputs Menu Parameters; Pump Status and Runtime Parameters

17
Outputs Menu – OUTPUTS
No. Name Status Unit Displayed text* Description
1 COMP_A o/on - Compressor A Compressor A status (circuit A)
2 OIL_SL_A o/on - Oil Solenoid Output A Oil solenoid output, circuit A
3 SLID_1_A o/on - Slide Valve 1 Output A Slide valve 1 output, circuit A
4 SLID_2_A o/on - Slide Valve 2 Output A Slide valve 2 output, circuit A
5 CAPT010A - V Capacity Signal Cir A 0-10V capacity signal, circuit A
6 COMP_B o/on - Compressor B Compressor B status (circuit B)
7 OIL_SL_B o/on - Oil Solenoid Output B Oil solenoid output, circuit B
8 SLID_1_B o/on - Slide Valve 1 Output B Slide valve 1 output, circuit B
9 SLID_2_B o/on - Slide Valve 2 Output B Slide valve 2 output, circuit B
10 CAPT010B - V Capacity Signal Cir B 0-10V capacity signal, circuit B
11 COMP_C o/on - Compressor C Not applicable to this unit
12 OIL_SL_C o/on - Oil Solenoid Output C Not applicable to this unit
13 SLID_1_C o/on - Slide Valve 1 Output C Not applicable to this unit
14 SLID_2_C o/on - Slide Valve 2 Output C Not applicable to this unit
15 CAPT010C - V Capacity Signal Cir C Not applicable to this unit
16 CAPT_010 - V Chiller Capacity signal Chiller capacity signal
17 ALARM o/on - Alarm Relay Status Alarm relay status
18 RUNNING o/on - Running Relay Status Running relay status
19 ALERT o/on - Alert Relay State Alert relay state
20 SHUTDOWN o/on - Shutdown Indicator State Shutdown indicator state
21 POS_3WV 0 to 100 % Cond 3 Way Valve Pos Condenser 3-way valve position
22 READY o/on - Ready or Running Status Unit ready/running status
23 ELBXFAN o/on - Electrical Box Fan Electrical box fan status
*Depends on the selected language (English by default).
Pump Status Menu – PUMPSTAT
No. Name Status Unit Displayed text* Description
1 SET_FLOW no/yes - Cooler Flow Setpoint Out Evaporator ow setpoint output
2 CPUMP_1 o/on - Cooler Pump #1 Command Evaporator pump 1 control enabled
3 CPUMP_2 o/on - Cooler Pump #2 Command Evaporator pump 2 control enabled
4 ROTCPUMP no/yes - Rotate Cooler Pumps ? Evaporator pumps rotation
5 FLOW_SW open/close - Cooler Flow Switch Evaporator ow switch
6 HPUMP_1 o/on - Condenser Pump Command1 Condenser pump control enabled
7 HPUMP_2 o/on - Condenser Pump Command2 Not applicable to this unit
8 ROTHPUMP no/yes - Rotate Condenser Pumps ? Not applicable to this unit
9 CONDFLOW open/close - Condenser Flow Status Condenser ow status
*Depends on the selected language (English by default).
Run Times Menu – RUNTIME
No. Name Status Unit Displayed text* Description
1 HR_MACH - hour Machine Operating Hours Unit operating hours
2 st_mach - - Machine Starts Number Number of unit starts
3 hr_cp_a - hour Compressor A Hours Operating hours, compressor A
4 st_cp_a - - Compressor A Starts Number of starts, compressor A
5 hr_cp_b - hour Compressor B Hours Operating hours, compressor B
6 st_cp_b - - Compressor B Starts Number of starts, compressor B
7 hr_cp_c - hour Compressor C Hours Not applicable to this unit
8 st_cp_c - - Compressor C Starts Not applicable to this unit
9 hr_cpum1 - hour Cooler Pump #1 Hours Operating hours, evaporator pump 1
