Carrier Touch Pilot - Schedule and Holiday Configuration; Broadcast and Date;Time Settings

21
Reset Conguration Menu – RESETCFG (continued)
No. Name Status Default Unit Displayed text* Description
15
16 Heating Heating
17 dt_hr_no 0 to 13.9 0 ^C Delta T No Reset Value Delta T, no reset value
18 dt_hr_fu 0 to 13.9 0 ^C Delta T Full Reset Value Delta T, max. reset value
19 v_hr_no 0 to 20 0 mA Current No Reset Value Current, no reset value
20 v_hr_fu 0 to 20 0 mA Current Full Reset Value Current, max. reset value
21 spahr_no -10 to 51.7 -10 °C Space T No Reset Value Space temperature, no reset value
22 spahr_fu -10 to 51.7 -10 °C Space T Full Reset Value Space temperature, max. reset value
23 hr_deg -16.7 to 16.7 0 ^C Heating Reset Deg. Value Maximum heating reset value
24 both_sel no/yes no - HSM Both Command Select HSM both command selection
25 auto_sel no/yes no - Auto Changeover Select Not applicable to this unit
*Depends on the selected language (English by default).
Schedule Menu – SCHEDULE
No. Name Displayed text* Description
1 OCCPC01S OCCPC01S - Schedule Menu Unit on/o time schedule
2 OCCPC02S OCCPC02S - Schedule Menu Unit setpoint selection time schedule
*Depends on the selected language (English by default).
Holiday Menu – HOLIDAY
No. Name Status Default Displayed text* Description
1 HOL_MON 0-12 0 Holiday Start Month Holiday start month
2 HOL_DAY 0-31 0 Start Day Holiday start day
3 HOL_LEN 0-99 0 Duration (days) Holiday duration (days)
*Depends on the selected language (English by default).
Broadcast Menu – BROCASTS
No. Name Status Default Displayed text* Description
1 ccnbroad 0/1/2 2 Activate Not applicable to this unit
2
3 OAT Broadcast
4 oatbusnm 0 to 239 0 Bus # Bus number of the unit with the outdoor temperature sensor
5 oatlocad 0 to 239 0 Element # Element number of the unit with the outdoor temperature sensor
6
7 dayl_sel Disable/Enable Disable DAYLIGHT SAVING SELECT Summer/winter time activation (daylight saving selection)
8 ENTERING
9 startmon 1 to 12 3 Month Month
10 startdow 1 to 7 7 Day of week (1=Monday) Day of the week **
11 startwom 1 to 5 5 Week Number of Month Week of the month
12 LEAVING
13 stopmon 1 to 12 10 Month Month
14 stoptdow 1 to 7 7 Day of week (1=Monday) Day of the week **
15 stopwom 1 to 5 5 Week Number of Month Week of the month
* Depends on the selected language (English by default).
** Daylight Saving Time (DST) usually starts/ends on Sunday morning (7). The clock goes 1 hour forward when entering and 1 hour backward when leaving DST.
The change normally occurs at 2:00 A.M.
