6. Calibration
■ What is calibration?
Calibration refers to the adjustment to make the displayed value consistent with the
actual weight on the display of weight.
■ Definition of each mode
☞ If the power is applied while any key is being pressed on the front, you may enter the test screen
mode.
- Press Key to return to TEST1 after the sequential increase in TEST1~9.
- Press Key to enter the Test Mode as desired. Please refer to the following
descriptions for each mode.
- Press Key again after setting or confirming each mode to return to TEST1.
(TEST3 is exceptional).
- Press Key to enter ST.CAL.
TEST 1
Zero weight value (A/D) can be confirmed.
TEST 2
Operations of each key can be confirmed.
TEST 3
Mode for the span calibration and equipment set under the SET, CAL mode.
☞ Press Key to return to each mode selection from this status.
TEST 4
It is Display Test Mode. Press Key to return to TEST.
TEST 5
It is Relay Output Test Mode. Press Key to return to TEST.
TEST 6
It is Input Test Mode. Press Key to return to TEST.
TEST 7
It is to select the analog amplification ratio. Press Key to return to TEST.
