CAS CI-1580A - Weighing Mode 4: Comparison Mode 2

31
“Communication Output” delay time(t1) setting
(upon the setting of F21-1, 2 Weighing Mode)
F22
10
00
∫
99
Delay time to the relay operation after SP2 relay operations can be
set.
* Reference
00 : Relay output during the stable weight
01 : Relay output after 0.1 second
99 : Relay output after 9.9 seconds
Delay Time of Relay Output for the Weighing Judgment
(F21-3 Checker Mode)
F24
10
01
∫
99
The delay time to the operation of relay for judgment after the
completion of weighing can be set.
* Reference
01 : Relay output after 0.1 second.
99 : Relay output after 9.9 seconds
