NEAR ZERO (EMPTY) RANGE SETTING
Range near zero to check the emptiness of the indicator
Ex) 000 : Near Zero Relay is operated when the display of weight is “0”.
010 : Near Zero Relay is operated when the display of weight is “10” or less.
150 : Near Zero Relay is operated when the display of weight is “150” or less.
Zero Display Range Setting
A function to set the display range of zero.
Ex) If 50 is set, any value not less than the value is all shown with 0
on the display.
If a value is set to F82, the value minus the value set to zero is displayed.
Ex) if 1000 is set, the zero value displayed in TEST1 Mode, for example, the value of
6000 is shown as 5000 after 1000 is deducted from the value.
Maximum Analog Output Setting
Maximum analog output of 0 ~ 10V, 4 ~ 20mA can be set.
Ex) If 1000 is set, 10V or 20mA output is done when the weight reaches 1000.
Equivalent Input Confirmation and Setting
Equivalent input can be confirmed and modified.
Calibration Span Constant Confirmation
Set the number to 89 using “ZERO” and “TARE” Key in F-Function Mode and press
“SET” Key to show span constant on the display.
