CAS CI-1580A - Relay Output ON Time for Weighing Judgment

33
※ Communication Setting
Serial Communication Parity Bit Setting mode
F30
●
0
No Parity
1
Odd Parity
2
Even Parity
Serial Communication : Baud Rate Setting
F31
0
115,200 bps
1
76,800 bps
2
57,600 bps
3
38,400 bps
4
28,800 bps
5
19,200 bps
6
14,400 bps
●
7
9,600 bps
8
4,800 bps
9
2,400 bps
Serial Communication Mode (When F33 is set to “0”)
F32
●
0
Stream Mode: Continuous output of weights all the time
1
Mode during the stable time: Data output at the time of stable
weighing
Serial Communication Mode
F33
0
Unilateral Transmission Mode
●
1
Command Mode
2
LCD Mode
4
External Display Mode
Equipment Number (ID NUMBER) Setting
F34
1
1~99
Number to be set for classification
Transmission Data Format
F35
●
0
BASIC FORMAT
1
CAS FORMAT
