CAS CI-1580A - Comprehensive F-FUNCTION List

22
53
0
AVERAGE DISPLAY SETTING MODE
00~99 0: No operation. 1~99: Under
operations
54
0
Steady LED Status Lamp Delay time
setting
0: No operation, 1: Operation.
55
0
Tension and Compression setting
0: No operation. (JP 1 OFF)
1: Operation. (JP 1 ON)
※F80~F89 can be entered after FUNCTION is designated.
(Refer to Page 22 How to enter after assigning F-Function
80
10
NEAR ZERO(EMPTY) RANGE SETTING
x x x x x x
81
0
ZERO DISPLAY RANGE SETTING
x x x x x x
82
xxxxxx
ZERO MINUS VALUE SETTING
x x x x x x
83
0
MAXIMUM ANALOG OUTPUT VALUE SETTING
x x x x x x
85
xxxxxx
INPUT OF EQUIVALENT CIRCUIT VALUE
x x x x x x
89
-
CHECK FOR CALIBRATION SPAN CONSTANT
x. x x x x x
Input
IN1
IN2
Use
Zero
Tare / Tare Removal
Output
OUT1
OUT2
OUT3
Use
SP3(Zero)
SP2(High Limit)
SP1(Low Limit)
