CAS CL series User Manual

125
2.14.14 Display Test (Menu code 1861)
( MENU → 8. SCALE CONFIG → 6. Test → 1. Display )
Pressing 1 while on the Test Menu screen will automatically initiate the Display Test
function. The Display Test will test the seven segment display as well as the LCD
graphic display. To exit the Display Test function simply press the X/ESC key and
you will be returned to the Test Menu screen.
2.14.15 A/D Test (Menu code 1862)
( MENU → 8. SCALE CONFIG → 6. Test → 2. A/D )
To test the A/D, press “2”
To set zero press “ZERO”
User may exit from this menu, using “X/ESC” key
2.14.16 Keyboard Test (Menu code 1863)
( MENU → 8. SCALE CONFIG → 6. Test → 3. Keyboard )
To test keyboard, press “3” Display will
show grid point Press any key to test key pad.
To exit keyboard test, press “ESC” two times.
2.14.17 Chess Printer Test (Menu code 1864)
( MENU → 8. SCALE CONFIG → 6. Test → 4. Chess Print )
Press “TEST” key to test printing a label.

CAS CL series Specifications

General

Display	LCD
Readability	0.1 g / 0.2 g / 0.5 g / 1 g
Interface	RS-232
Units	g, kg, lb, oz
Features	Counting, percentage weighing, checkweighing
Material	Stainless steel
Capacity	6 kg / 15 kg / 30 kg
