CAS CL3500 Series - Page 36

36
CAS ELECTRICS CO.,LTD
4.2.4 Linearity Fine Adjust (Menu Code 8184)
(Calibration MENU -> 1. Calibration -> 8. Factory Setting -> 4. Linearity Fine Adjust)
①
Selecting“LinearityFineAdjust”
NOTE: You can set 0 by pushing “ZERO” This will update new Zero value.
② MENU 8106 Put 5kg(MAX=15kg) on the tray.
③ Using cursor key for fine adjust.
* How to use cursor key
“ ” ▶ Increase Span value( ⓓ ) to reduce internal ( ⓑ )value
“ “ ▶ Decrease Span value( ⓓ ) to increase internal ( ⓑ )value
- Setting Mid value press “ ▼ ”key
- Internal value 20005 to change 20000 press “ ” ▶ 5times.
* How to input setting value
- Use cursor key to change mid value.
- Insert “36537” then press “TEST”
Also ④ change Span value with cursor key.
⑤ Press “SAVE” to save and exit.
8184 60000 15000
LINEARITY
FINE ADJUST
(1/
1
)
Zero:[ 10730]
Mid :[ 36537]
Span:[ 88145]
8184 20005 5002
LINEARITY
FINE ADJUST
(1/
1
)
Zero:[ 10730]
Mid :[ 36537]
Span:[ 88145]
8184 0 0
LINEARITY
FINE ADJUST
(1/
1
)
Zero:[ 10730]
Mid :[ 36532]
Span:[ 88145]
ⓐ Menu Code ⓑ Internal value ⓒ External V.(weight) ⓓ Real value of Zero & Span
