Case CX235C SR - Side Doors

3-CONTROLS/INSTRUMENTS
Sidedoors
WARNING
Movingparts!
Makesureallentryandmechanicalaccessdoorsareproperlyclosedbeforeoperatingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0238A
Usetheoutsidehandletoopenthedoors.Toholdthedoors,open,removethestrutsfromtheirstoragepositionand
installthemintheholesprovided.Whenclosing,putthestrutsbackintotheirstoragehousing.
NOTICE:Alwaysinstallthestrutswhenthedoorsareopen.
ATTENTION:Neverleavetoolsorotherobjectsbehindthesidedoors.
NOTE:Usetheignitionkeytolockthesidedoors.
Right-handdoor
Theright-handdoorgivesaccesstocertainhydraulic
components(pump,lter,etc.)andalsototheengine
fuelandoillters.
C6750B851
Left-handdoor
Theleft-handdoorismainlyforobtainingaccesstothe
batteries,batterymasterswitch(ifequipped),windshield
washertank,airlter,radiator,oilcooler,etc.
BC59A3CB2
3-67
