4-OPERATINGINSTRUCTIONS
MOVINGTHEUNIT
Machinetravel
WARNING
Controlscanbereversed!
Inthenormaltravelposition,theoperator's
compartmentisabovetheidlerwheelsandthe
travelreductiongearsaretotherearoftheup-
perstructure.Iftheupperstructureisturned
180degreesinrelationtotheundercarriage,
thecontrolsarereversed.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0289A
ATTENTION:Beforeundertakinganytravel,raisetheat-
tachmentandthedozerblade(ifequipped).
NOTE:Travelspeeddependsonthetiltingangleofthe
travelcontrolleversandpedalsandthespeedtravel
modeselected.
NOTE:Thedifferenttravelcongurationsdescribedhere-
afterarewiththetravelreductiongearstotherearofthe
upperstructure.
82EE1F3D1
Travelalarm
Thetravelalarmsoundscontinuouslyorfor10seconds,
dependingthepositionoftheswitch.(Refertopage3-53).
Straightlinetravel(forwardtravel)
Pressthetwopedals(orpushthetwolevers)forwardat
thesametimeorpressthepedallocatedontheright.
CS98M546Z2
4-15
