Case CX235C SR - Fan and Alternator Drive Belt

6-MAINTENANCE
Fanandalternatordrivebelt
Servicespecications
Visualcheck:Every10hoursoreveryday
Checkbelttension:Every250hours
Checkingthetension
NOTICE:Iftheenginerunswiththebeltslack,thebelt
canslipinitshousingandcausetheenginetooverheat
orthebatterytoreceiveinsufcientcharge.
1IUTUH-002A1
Withengineshutdownandtheignitionkeyremoved,use
yourngertoexertapressureofabout10kg(22.0lb)at
thecentreofthebelt.
Thetensionslackshouldbebetweenabout6mm(0.2in)
and8mm(0.3in).
NOTE:Checkifthereareanysignsofweardamageto
thepulleysorthebelt.Checkcarefullytoensurethatthe
beltiscorrectlypositionedinthepulleygrooves.Ifthebelt
isstretched,crackedorfrayed,itmustbereplaced.
CS98M560TBP12
Adjustingthetension
Removetheretainingscrews(1)and(2).Usetheadjust-
mentscrews(3)tomovethealternatoroutwardsuntilbelt
tensioniscorrect.Tightenthealternatormountingbolts
(1)and(2).
5PJHCJ-0013
