Case CX235C SR - Travel Reduction Gears

6-MAINTENANCE
Travelreductiongears
Servicespecications
Oillevelcheck:Every250hours
Oildrain:Every1000hours(aftertherst250hoursduringtherun-inperiod)
Oilcapacity(perreductiongear):5l(1.3USgal)
Typeofoil:(Refertopage6-5)
Level
1.Parkthemachineonat,horizontalground.
2.Movethemachinesothatplug(1)isinthelowest
possibleposition.
3.Stoptheengineandremovetheignitionkey.
4.Slowlyloosentheplug(3)toreleaseanyresidualpres-
sure.
5.Removetheplug(2)andchecktheoillevel.Thelevel
mustcomeuptothebottomedgeoftheport(2).If
required,removetheplug(3)andtopupthroughthis
portuntiloilcomesuptothebottomedgeoftheport
(2).
6.Ifnecessary,replacethesealsofplugs(2)and(3)then
replacetheplugs.
7.RepeatSteps2to6fortheothertravelreductiongear.
8.Travelslowlywiththemachineandmakesurethere
arenoleaks.
