Case CX235C SR - Overall Machine Dimensions (without Dozer Blade)

8-SPECIFICATIONS
Dimension
Overallmachinedimensions(withoutdozerblade)
BFFCA6C11
Arms
2.40m(94.49in)2.94m(115.75in)
(A)3.18m(125.20in)2.96m(116.54in)
(B)(withouttopgardOPG)3.04m(119.69in)3.04m(119.69in)
(C)8.92m(351.18in)8.83m(347.64in)
(E)2.99m(117.72in)2.99m(117.72in)
(F)1.02m(40.16in)1.02m(40.16in)
(G)2.23m(87.80in)2.23m(87.80in)
(H)4.47m(175.98in)4.47m(175.98in)
(I)3.66m(144.09in)3.66m(144.09in)
(J)2.39m(94.09in)2.39m(94.09in)
(K)(standardtrackpads)0.8m(31.50in)0.8m(31.50in)
(L)3.19m(125.59in)3.19m(125.59in)
(M)0.44m(17.32in)0.44m(17.32in)
(N)3.09m(121.65in)3.09m(121.65in)
8-5
