6-MAINTENANCE

Airlter

Inspection

Besuretocarryoutregularchecksontheairlter,intakemanifold,sealsandhoses.Atthesametime,checkthe

intakemanifoldscrewsandhoseclampsfortightness.

Thehosesshouldbechangedbeforetheyareworn.

Servicespecications

Inspectandcleantheprimaryelement:Every250hoursorwhenthe"Airlter"messageisdisplayedonthemessage

displayscreen

Replacetheprimaryelement:Every1000hoursoraftercleaning6times

Replacethesecondaryelement:Every1000hoursoraftercleaningthemainelement3times

ATTENTION:Theprimaryelementcanbecleaned.Thesecondaryelementcannotbecleanedandmustbechanged.

NOTICE:Observetheairlterserviceintervalsshownabove.Cleanltersmeanlongerenginelife.

Removingtheelements

1.Releasethefastenersandremovethecover.

45DFC4621

2.Removetheprimaryelement.

76E474B42

6-45
