Case CX235C SR - Fuel Tank Filler Pump (if Equipped)

3-CONTROLS/INSTRUMENTS
Fueltankllerpump(ifequipped)
WARNING
Firehazard!
Whenhandlingdieselfuel,observethefollowingprecautions:
1.Donotsmoke.
2.Neverllthetankwhentheengineisrunning.
3.Wipeupspilledfuelimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0099A
NOTICE:Donotputamoistureeliminationproduct(waterdrainingagent)inthefueltank.(Itmaydamagetheengine).
ATTENTION:Thispumpislocatedinthefrontstorageboxandistobeusedforfuelonly.Usesuitablefuel,(referto
page6-5).
1.Parkthemachineonat,horizontalground,stopthe
engineandsettheignitionkeytothe“On”position
(contact).
2.Taketheinletpipeoutofthestoragecompartment.
FBF328111
3.Measuretheheightofthedrumandplacetheidenti-
cationclamp(1)ofthesuctiontubeatalengthslightly
lessthanthatofthedrumheight.
4.Makesurethattheendstrainerofthesuctiontubeis
correctlyattachedandtheninsertthesuctiontubein
thedrum.
8VHZ5J-0022
5.Removethefueltankllercap.
WARNING
Burnhazard!
Ifthellercapremainsonduringtherefuel-
ingprocess,removingthecapafterrefueling
couldcauseanaccident.Toreducethisrisk,
ALWAYSremovethefueltankllercapbefore
refuelingwiththefueltankllingpump.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0247A
619C190B3
3-74
