4-OPERATINGINSTRUCTIONS
Adjustthemirrortoseethefrontright(track)ofthema-
chine.
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
F31B0E824
Ontheupperstructure(front)
Adjustthemirrortoseetherightrearedgeofthemachine
bysight.
(L)dimension:285mm(11.2in).
2A7C66815
Adjustthemirrortoseethesideofthemachine.
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
542302636
Ontheupperstructure(rear)
Adjustthemirrortoseetherightfrontedgeofthemachine
bysight.
(L)dimension:285mm(11.2in).
CF4C31DB7
